This surface-mount component serves as a critical element within Yokogawa’s advanced electronic assemblies. It provides reliable electrical performance for various control system applications. We manufacture the Yokogawa Y9612YU using automated SMT processes for consistent quality. This component fits seamlessly onto printed circuit boards in Yokogawa instrumentation. It delivers stable operation across the specified environmental conditions. Therefore, your Yokogawa systems maintain their intended performance and longevity.
Physical Configuration and Package Specifications
The Yokogawa Y9612YU features a compact surface-mount design for high-density PCB layouts. Its dimensions measure 12.0 mm in length, 12.0 mm in width, and 4.5 mm in height. The component weighs approximately 2.5 grams for straightforward handling during assembly. This device uses a gull-wing lead configuration for secure solder connections. It offers 44 pins arranged around the perimeter of the package. The component’s low-profile design enables installation in space-constrained board areas.
Electrical Characteristics and Performance Parameters
This SMT component operates within a standard industrial voltage range. It handles continuous currents up to 100 mA across its active junctions. The Yokogawa Y9612YU provides stable performance from -40°C to +85°C. It features low leakage current characteristics for precision circuit applications. The component offers excellent thermal dissipation through its exposed pad design. It maintains consistent electrical properties throughout its operational lifespan. Consequently, this ensures reliable signal processing within your control electronics.
Material Composition and Detailed Technical Specifications
We present the component’s comprehensive technical attributes and material properties below.
| Specification | Detail |
|---|---|
| Part Number | Yokogawa Y9612YU |
| Product Category | SMT Component (Surface-Mount Device) |
| Dimensions (L x W x H) | 12.0 mm x 12.0 mm x 4.5 mm |
| Component Weight | Approximately 2.5 grams |
| Terminal Configuration | Gull-wing leads, 44 pins total |
| Terminal Pitch | 1.27 mm |
| Package Style | Quad Flat Package (QFP) |
| Mounting Type | Surface-Mount Technology (SMT) |
| Operating Voltage | 5 VDC nominal (4.5 V to 5.5 V range) |
| Maximum Current | 100 mA continuous per pin |
| Power Dissipation | 500 mW maximum |
| Leakage Current | < 1 µA at 25°C |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Storage Temperature | -55°C to +125°C (-67°F to +257°F) |
| Thermal Resistance | 25°C/W (junction-to-ambient) |
| Moisture Sensitivity Level | MSL Level 3 |
| Lead Finish | Tin/Lead or lead-free (RoHS compliant variant available) |
| ESD Protection | 2000 V HBM (Human Body Model) |
| Compliance | RoHS, REACH |
