Product Overview
The Yokogawa F9342BB-00 delivers high-precision pressure measurement for demanding industrial applications. This transmitter belongs to the DPharp series and provides accurate and reliable data for process control systems. The device converts physical pressure into a standardized 4-20 mA output signal for seamless integration with DCS and PLC platforms.
Technical Specifications
The Yokogawa F9342BB-00 incorporates advanced digital sensing technology for superior measurement stability. Its robust stainless steel housing withstands harsh environmental conditions in processing plants. The unit supports HART communication for remote configuration and real-time diagnostics.
| Parameter | Specification |
|---|---|
| Product Type | Pressure Transmitter |
| Series | DPharp Series |
| Accuracy | ±0.075% of span (includes non-linearity, hysteresis, repeatability) |
| Output Signal | 4-20 mA with HART® protocol |
| Protocol Version | BRAIN protocol version (standard) |
| Process Temperature | -40°C to +85°C (-40°F to +185°F) |
| Ambient Temperature | -40°C to +85°C (-40°F to +185°F) |
| Overpressure Capability | Up to 200% of rated range |
| Housing Material | Stainless steel |
| Protection Rating | IP67 (dust-tight and waterproof) |
| Power Supply | 12 to 42 V DC |
| Country of Origin | Japan |
Measurement and Communication
This pressure transmitter features a self-diagnostic function for simplified troubleshooting. The Yokogawa F9342BB-00 communicates via the BRAIN protocol, while variant models support HART or intrinsically safe configurations. Users can perform remote calibration and parameter adjustments through the digital communication interface.
Application Scenarios
Process industries deploy this device for measuring liquid, gas, and steam pressures in pipelines and vessels. The Yokogawa F9342BB-00 suits applications in oil and gas, chemical, and power generation facilities. Its robust design ensures reliable operation in outdoor and hazardous locations.
Details
| Weight | 3.6 kg |
|---|---|
| Dimensions | 190 × 108 × 135 mm |
