Smart Communication for Pressure Measurement

The Yokogawa F9342AM integrates a differential pressure transmitter with advanced fieldbus communication capabilities. This communicator provides a reference accuracy of 0.075% of span for reliable process data . It delivers a 4 to 20 mA analog output alongside HART digital protocol support . Consequently, this device enables seamless digital plant integration and remote asset management.

Pressure Range and Dynamic Performance

The F9342AM handles static pressures up to 16 MPa for demanding industrial services . Its turndown ratio extends to 100:1 for flexible measurement range configuration . The device responds to pressure changes within 100 milliseconds for effective process control . Moreover, temperature-induced errors remain below 0.05% per 10 °C for consistent accuracy .

Fieldbus Communication and Diagnostic Capabilities

This communicator uses a silicon resonant sensor for excellent long-term stability . The Yokogawa F9342AM supports HART communication for remote configuration and diagnostics . It enables multivariable data transmission for comprehensive process monitoring . Additionally, this device provides self-diagnostic functions for predictive maintenance planning .

Construction Materials and Physical Specifications

Wetted parts feature Hastelloy C276 for outstanding resistance to corrosive fluids . The housing combines stainless steel with a polyurethane-coated aluminum cover for ruggedness . The F9342AM weighs 36 kilograms and measures approximately 240 x 180 x 160 millimeters . It supports 2-inch pipe mounting or direct flange installation .

Environmental Range and Safety Certifications

This device operates reliably within -40 to 85 °C ambient temperatures . It stores safely from -50 to 90 °C for extended periods . The Yokogawa F9342AM carries an IP67 protection rating for outdoor installations . It also meets SIL 2 safety integrity level requirements for critical processes .
