Product Overview
The Yokogawa CP313D operates as a processor module for Yokogawa distributed control systems. This unit executes control logic, sequence programs, and regulatory algorithms in real time. Consequently, plant engineers maintain stable process control across the entire facility.
Technical Specifications
| Parameter | Detail |
|---|---|
| Model | CP313D |
| Brand | Yokogawa |
| Category | Processor Module |
| Compatible Systems | CENTUM VP, CENTUM CS 3000 |
| Processor Type | 32-bit RISC CPU |
| Memory | 16 MB control memory |
| Control Functions | PID, sequence, arithmetic |
| Communication Ports | Dual redundant bus interfaces |
| Weight | Approximately 0.5 kg |
| Dimensions | 32.8 mm × 107.5 mm × 130 mm |
| Operating Voltage | 24 V DC nominal |
| Power Consumption | Approximately 5 W |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Mounting Style | Rack-mounted card |
| Component Count | One module, one backplane connector |
| Energy Storage | Battery-backed SRAM for parameters |
Design and Construction
This module occupies one slot in a standard controller rack, which conserves cabinet space. Additionally, the front panel carries run and fault LEDs, so technicians verify status quickly. The backplane connector links the card with I/O buses reliably. Moreover, the housing shields internal circuits from dust and vibration.
Compatibility and Installation
This processor pairs with CENTUM VP controllers and Yokogawa I/O nests. During commissioning, engineers should download current configuration files, because outdated logic causes control errors. Furthermore, the module supports redundant pairs for high-availability processes. The 24 V DC supply keeps cabinet wiring simple and consistent.
Key Benefits
Process plants choose this module for its fast execution and redundant architecture. As a result, it handles complex control loops without slowing cycle times. This model also retains parameters through battery backup during outages. Ultimately, its dependable performance reduces downtime and maintenance costs.
Details
| Weight | 0.35 kg |
|---|---|
| Dimensions | 120 × 52 × 125 mm |
