Core Technical Parameters

The Yokogawa ANB10S operates as a dedicated ESB bus node unit for the CENTUM VP distributed control system. This module features compact dimensions of 130 mm in height, 54 mm in width, and 120 mm in depth. It weighs approximately 0.8 kilograms for straightforward handling during installation. The unit draws 0.3 A from a 24 V DC power supply, consuming 7.2 W under full load. It incorporates a single ESB bus interface port for backbone network connectivity. The module includes 128 MB of onboard flash memory for firmware retention. It also provides 64 MB of RAM for efficient data buffering operations.

The unit supports a maximum transmission distance of 185 meters per bus segment. It offers optical isolation between the bus and internal logic circuits. The operating temperature range spans -10°C to 55°C for diverse environments. Storage temperatures can extend from -20°C to 70°C without damage. Humidity tolerance covers 10% to 90% non-condensing conditions for reliable operation.

System Integration and Communication Features

This node unit manages data exchange at a transmission speed of 10 Mbps across the ESB backbone. It supports up to 64 connected devices per bus segment for scalable system design. The Yokogawa ANB10S includes dual LED indicators for power and communication status monitoring. It provides electrostatic discharge protection up to 6 kV for enhanced durability. The unit incorporates a built-in watchdog timer for automatic system recovery during faults. It utilizes a 14-pin terminal block for straightforward external wiring connections. Configuration parameters reside in non-volatile memory to preserve settings after power loss. The module supports hot-swappable replacement to minimize system downtime during maintenance. It complies with IEC 61131-2 standards for industrial automation equipment. The unit features a protective coating on the PCB to resist dust and moisture ingress. It includes a ground terminal for proper chassis earthing to reduce electrical interference.

Installation and Reliability Data

The ANB10S mounts directly onto a standard DIN rail for simple panel integration. It requires 50 mm clearance above and below for adequate airflow around the unit. The module offers a mean time between failures of 500,000 hours for long-term dependability. It carries CE marking and UL recognition for global deployment flexibility. The unit passes vibration testing at 5 to 8.4 Hz with 3.5 mm amplitude. It withstands shock loads up to 15 g for 11 ms duration without performance degradation. Event logs store in 8 MB of dedicated buffer memory for troubleshooting purposes. Firmware updates occur via the ESB bus for future feature enhancements. The unit incorporates a single printed circuit board assembly with integrated communication processors. This design simplifies maintenance and reduces potential failure points significantly.
