Key Technical Specifications

The Yokogawa ANB10D S1 functions as a dedicated ESB bus node unit within the CENTUM VP distributed control system. This module measures 130 mm in height, 54 mm in width, and 120 mm in depth. It weighs approximately 0.8 kilograms, making it lightweight for easy installation. The unit operates on a 24 V DC power supply with a typical current draw of 0.3 A. It features one ESB bus interface port for seamless backbone connectivity. The module contains a single printed circuit board assembly with integrated communication processors.

It includes 128 MB of onboard flash memory for firmware storage and 64 MB of RAM for data buffering. The unit supports a maximum transmission distance of 185 meters per segment. It provides optical isolation between the bus and internal logic circuits for enhanced noise immunity. The operating temperature ranges from -10°C to 55°C, while storage allows -20°C to 70°C. Humidity tolerance spans 10% to 90% non-condensing for reliable performance.

Functional Overview and System Integration

This node unit acts as a critical bridge between field control stations and the ESB bus backbone. It manages data exchange at a transmission speed of 10 Mbps. The ANB10D S1 supports up to 64 connected devices per bus segment for scalable system architecture. It incorporates dual LED indicators for power and communication status monitoring. The unit provides electrostatic discharge protection up to 6 kV for robust operation. It includes a built-in watchdog timer for automatic reset during fault conditions. The module consumes 7.2 W of power under full load conditions. It utilizes a 14-pin terminal block for external wiring connections. The unit stores configuration parameters in non-volatile memory to retain settings after power cycles. It supports hot-swappable replacement without system shutdown for minimal downtime. The node unit complies with IEC 61131-2 standards for industrial automation equipment.

Installation and Environmental Compliance

The ANB10D S1 mounts onto a standard DIN rail for straightforward panel integration. It requires a minimum clearance of 50 mm above and below for adequate ventilation. The unit features a protective coating on the PCB to resist dust and moisture ingress. It includes a ground terminal for proper chassis earthing to reduce electrical noise. The module offers a mean time between failures of 500,000 hours for long-term reliability. It carries CE marking and UL recognition for international deployment. The unit passes vibration testing at 5 to 8.4 Hz with 3.5 mm amplitude. It withstands shock loads up to 15 g for 11 ms duration. The node unit stores event logs in 8 MB of dedicated buffer memory. It supports firmware updates via the ESB bus for future feature enhancements.
