Input Management Overview

The Yokogawa AMM22 S3 functions as a multiplexer input module for the CENTUM CS and VP series distributed control systems. This module scans multiple analog inputs and forwards the data to the field control unit. It offers flexible configuration for both voltage and current signal types. Process industries employ this module for efficient signal acquisition from field transmitters.

Technical Specifications

The AMM22 S3 measures 128 mm in height and 33 mm in width. Its compact form factor optimizes space in Yokogawa I/O racks. The module weighs approximately 0.25 kilograms. It draws 420 mA from the +5V DC and 45 mA from the ±15V DC supplies.

Signal Type Flexibility and Input Configuration

This module accepts both current and voltage signals through the same input terminals. The software selects the appropriate input type for each channel individually. A shunt resistor array provides the 250 Ω termination for current signals. The instrumentation amplifier handles voltage signals with high common-mode rejection. Each channel measures with 16-bit resolution for precise data acquisition. The module supports mixed configurations of current and voltage inputs.

Multiplexing Architecture and Speed

The Yokogawa AMM22 S3 sequences through all sixteen channels in rapid succession. Each channel acquisition takes only 80 microseconds for fast system response. Two multiplexer ICs manage the scanning with minimal settling time. A 22 μF electrolytic capacitor stabilizes the supply for consistent performance. The module provides anti-aliasing filtering on each input channel. This filtering eliminates high-frequency noise from industrial environments.

Connectivity and System Integration

Installing the AMM22 S3 requires a single slot in the Yokogawa I/O rack. The module connects via a 50-pin ribbon cable to the field marshalling cabinet. A green LED confirms proper power and a yellow LED blinks during scanning. The module communicates with the field control unit through the backplane bus. It operates reliably between 0°C and 50°C ambient temperatures. Proper cable shielding prevents electromagnetic interference.

Reliability and Calibration

The Yokogawa AMM22 S3 maintains accuracy through factory calibration and autozeroing. The module stores calibration coefficients in non-volatile memory. Regular diagnostics check the multiplexer and amplifier performance. The module’s solid-state design ensures long-term reliability without moving parts.
