Technical Overview
The Yokogawa AFS30S and AFS30D modules serve as dedicated Ethernet communication processors for the CENTUM VP and CS 3000 DCS environments. These units enable high-speed data exchange between the Field Control Unit and external subsystems like PLCs, analyzers, and plant management networks. Consequently, they eliminate the need for third-party protocol converters and significantly reduce communication latency. For non-redundant network paths, the single AFS30S provides a cost-effective solution. Meanwhile, the duplexed AFS30D supports redundant module configurations, thereby ensuring uninterrupted operation for critical processes.
Hardware Specifications
Both modules feature a compact footprint of 100 mm (W) x 100 mm (H) x 30 mm (D), optimizing cabinet space in high-density racks. The AFS30S and AFS30D weigh approximately 0.2 kg, making them lightweight and easy to handle during installation. They feature a standard RJ45 port and support communication speeds up to 100 Mbps.
| Specification | Value |
|---|---|
| Model | AFS30S (Single) / AFS30D (Duplexed) |
| Communication Speed | Up to 100 Mbps |
| Port Type | RJ45 |
| Dimensions (W x H x D) | 100 mm x 100 mm x 30 mm |
| Weight | 0.2 kg |
| Protocol Support | Ethernet/IP, Modbus TCP, PROFINET IO, EtherCAT |
Protocol Compatibility and Integration
The modules support a wide range of industrial protocols, including Ethernet/IP, Modbus TCP, PROFINET IO, and EtherCAT. This broad compatibility ensures seamless integration with diverse third-party devices and legacy systems. The Yokogawa AFS30S and AFS30D mount directly onto field control units, ESB bus node units, and ER bus node units. Furthermore, their real-time diagnostic LEDs provide instant status feedback, allowing maintenance teams to quickly identify and resolve network issues.
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
