Redundant Control Engine for Critical Process Applications
The AFS10D/AFG10D function as duplexed field control units within the CENTUM VP and CS 3000 DCS ecosystems . These units execute deterministic control logic while maintaining continuous process uptime through dual-redundant architectures . They interface directly with Remote I/O nodes via the Vnet/IP control network . This design effectively eliminates single points of failure in mission-critical industrial environments.
Technical Specifications
The table below details the key technical parameters for these duplexed field control units.
| Parameter | AFS10D / AFG10D Specification |
|---|---|
| Architecture | Duplexed (Dual-Redundant) Processor System |
| Input Voltage Options | 100-120 V AC, 220-240 V AC, or 24 V DC |
| Power Consumption (AC) | 400 VA (100-120 V) / 410 VA (220-240 V) |
| Power Consumption (DC) | 8 A (24 V DC input) |
| Network Interface | Dual-redundant Vnet/IP |
| Memory Backup | Battery backup provides up to 72 hours of data retention |
| Mounting | 19-inch rack mountable |
| Weight | Approx. 8.0 – 9.0 kg |
| Operating Temperature | 0 to 50 °C |
| Protection | Built-in 8A/250V rated fuse; recommend 15A/250V external breaker |
Configuration and Application Flexibility
The AFS10D/AFG10D offer multiple power input options to suit various plant infrastructures . Both units support a dual-redundant configuration across processors, power supplies, and communication paths . They are compatible with both FIO and RIO I/O module families, providing flexibility for system design . Furthermore, these units maintain robust performance under demanding conditions, with high vibration and shock resistance ratings .
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
