Overview of the Yokogawa ADV161-P01 Digital Input Module

The ADV161-P01 operates as a digital input module within Yokogawa’s distributed control systems. This unit captures discrete field signals and forwards them to the host controller. Engineers deploy it in process plants that demand dependable status monitoring.

Key Technical Specifications of the ADV161-P01

The ADV161-P01 combines a rugged housing with a secure field wiring interface. Below you will find the core parameters that define this module’s performance envelope.

Physical Design and Interface Details

The ADV161-P01 adopts a compact footprint that fits standard Yokogawa I/O racks. Its dimensions measure 130 mm in length, 100 mm in width, and 25 mm in depth. Moreover, the module weighs roughly 250 grams, which simplifies rack installation and field replacement. Twenty screw terminals secure field wiring without specialized tooling.

Performance and Signal Acquisition Capabilities

This module provides sixteen discrete input channels for versatile status monitoring. Each channel draws roughly 6 mA at 24 V DC during normal operation. Optical isolation separates field circuits from internal logic, which protects sensitive control electronics. Additionally, the module recognises a 15 V DC minimum threshold for a valid ON state. Consequently, the unit suits high-density input applications in automated plants.

Power and Environmental Considerations

The ADV161-P01 operates on a 24 V DC nominal power supply. Power consumption remains approximately 3 W during normal operation. The operating temperature range spans 0°C to 55°C for industrial environments. Storage temperature extends from -20°C to 70°C. Furthermore, humidity tolerance reaches 95% RH without condensation.
