Technical Overview
The XYCOM PM8500 operator interface combines a bright 12.1-inch color TFT display with a responsive touchscreen for industrial human-machine interaction. This rugged panel delivers real-time process visualization and control commands to PLCs and DCS systems across the factory floor. The bright TFT screen provides clear visibility even in direct sunlight or low-light conditions. Furthermore, the PM8500 supports multiple communication protocols, including Modbus and Ethernet/IP, for seamless integration with existing automation networks.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Model | XYCOM PM8500 |
| Product Type | Operator Interface / HMI Panel |
| Display Size | 12.1 inches diagonal |
| Display Type | Color TFT LCD |
| Resolution | 800 × 600 pixels (SVGA) |
| Touchscreen | Resistive analog touchscreen |
| Communication Ports | Ethernet, RS-232, RS-485, USB |
| Processor | High-performance 32-bit RISC |
| Storage | 128 MB SDRAM, 64 MB Flash |
| Power Input | 18-36 V DC or 100-240 V AC |
| Power Consumption | 35 W typical |
| Protection Rating | NEMA 4X / IP65 (front panel) |
| Mounting | Panel mount or VESA |
| Operating Temperature | 0°C to 50°C |
| Dimensions (W × H × D) | 312 mm × 243 mm × 56 mm |
| Unit Weight | Approximately 3.2 kg |
Performance and Application Benefits
The PM8500 features a 32-bit RISC processor and 128 MB SDRAM for smooth graphics rendering and fast page navigation. The 64 MB Flash memory stores application files and historical data logs locally, reducing reliance on external storage. The resistive touchscreen responds accurately to gloved hands, making it suitable for industrial environments where operators wear protective gear. The integrated Ethernet port enables high-speed data exchange and remote diagnostics over the plant network. Multiple serial ports support legacy equipment integration through RS-232 and RS-485 connections. The NEMA 4X rated front panel withstands water, dust, and chemical exposure, ensuring dependable performance in harsh conditions. The universal power supply accepts either DC or AC input, simplifying installation across various plant locations. Built-in diagnostic routines monitor system health and alert operators to potential issues.
Details
| Weight | 2.85 kg |
|---|---|
| Dimensions | 41.2 × 17.8 × 6.2 mm |
