This Xycom automation module provides flexible control and monitoring for industrial systems. The Xycom 9450 9450-29H432G010000 handles both discrete and analog signals with high reliability. Its modular architecture simplifies system configuration and future upgrades. This module suits a wide range of manufacturing and process applications.
Physical Dimensions and Mounting Specifications
The module measures 230 mm in height and 28 mm in width. Its overall depth reaches 175 mm including the front connector. This unit weighs approximately 0.55 kilograms for stable installation. The housing supports standard DIN rail mounting in control cabinets. The Xycom 9450 9450-29H432G010000 features a 20-pin front connector for all signal wiring. This connector accepts conductor cross-sections from 0.5 mm² to 2.5 mm².
Processor and Memory Specifications
An integrated 16-bit microprocessor executes user programs with consistent performance. The processor operates at a clock frequency of 10 MHz for efficient processing. This unit includes 64 KB of RAM for user program and data storage. A separate 128 KB EPROM holds the operating system firmware. The Xycom 9450 9450-29H432G010000 provides 32 KB of retentive memory for critical data. An internal supercapacitor maintains memory for approximately 14 days without external power. A battery backup option extends the data retention period significantly.
I/O Configuration and Communication Ports
This module provides 24 digital inputs for direct sensor and switch connection. It includes 16 digital outputs for actuator and relay control applications. Each output drives loads up to 0.5 A at 24 V DC for reliable switching. The unit offers one RS-232 port for programming and diagnostic communication. A second RS-485 port supports multi-drop network connections with other devices. The Xycom 9450 9450-29H432G010000 includes four analog inputs for process monitoring and control.
Detailed Specification Table
| Parameter | Specification |
|---|---|
| Dimensions (H x W x D) | 230 mm x 28 mm x 175 mm |
| Weight | Approx. 0.55 kg |
| Processor Type | 16-bit microprocessor |
| Clock Frequency | 10 MHz |
| RAM Capacity | 64 KB |
| EPROM Capacity | 128 KB |
| Retentive Memory | 32 KB |
| Data Retention Time | Approx. 14 days (supercapacitor) |
| Digital Inputs | 24 |
| Digital Outputs | 16 (0.5 A @ 24 V DC) |
| Analog Inputs | 4 |
| Communication Ports | RS-232, RS-485 |
| Connector Type | 20-pin front connector |
| Operating Temperature | 0°C to 55°C |
Application and Installation Guidelines
Mount this module vertically on a DIN rail within a control cabinet. Ensure adequate clearance around the module for proper heat dissipation. Connect field devices using shielded cables for reliable signal transmission. The Xycom 9450 9450-29H432G010000 operates effectively between 0°C and 55°C. Download the user program via the RS-232 interface from a programming device. Connect the RS-485 port for networked multi-drop communication. Regularly inspect terminal connections to maintain reliable system performance.
