This Xycom operator interface terminal provides robust monitoring and control for industrial applications. The Xycom 4810ER features a bright display for clear machine status visualization. Its rugged design withstands extreme temperatures and mechanical vibration. This terminal suits remote equipment monitoring and factory floor installations.

Display and Physical Specifications

The terminal incorporates a 10.4-inch monochrome LCD with 640 x 400 pixel resolution. The display area measures 211 mm by 132 mm for effective viewing. Its overall dimensions reach 320 mm in width and 245 mm in height. The depth measures 90 mm behind the mounting surface. This unit weighs approximately 3.5 kilograms for stable panel installation. The Xycom 4810ER includes an infrared touchscreen for non-contact operator input. Eight membrane keys provide emergency and function control access.

Electrical Specifications and Interface Options

This terminal draws a nominal current of 650 mA from a 24 V DC supply. Peak inrush current reaches 3.5 A for approximately 35 milliseconds during startup. The device consumes about 16 W of power during normal continuous operation. The terminal provides one RS-232 port for programming and host communication. A second RS-422/485 port supports multi-drop network connections. The Xycom 4810ER includes a 10/100 Mbit/s Ethernet port for network integration. The unit features 8 MB of flash memory for application and data storage. An internal 1000 µF capacitor provides energy storage for brief power interruptions.

Environmental Ratings and Mounting Guidelines

Operating temperatures range from -10°C to 60°C for extreme condition performance. Storage temperatures extend from -30°C to 80°C without causing damage. Relative humidity tolerance reaches 95% with no condensation forming on surfaces. The front panel meets NEMA 4X and IP66 protection against dust and high-pressure water. The Xycom 4810ER includes a heater for cold-start operation below 0°C. Mount this panel using the provided corrosion-resistant brackets for a secure fit.

Detailed Specification Table

Application and Installation Guidelines

Install this terminal in a clean, vibration-free location on the machine front. Cut a 290 mm x 215 mm opening in the control desk panel. Insert the unit from the front and secure it using the provided brackets. Connect the communication cables before applying power to the unit. The Xycom 4810ER supports configuration via the manufacturer’s software tools. Use the membrane keys for emergency stop and system reset functions. Clean the infrared touchscreen surface with a soft, dry cloth regularly. Verify the communication settings match the connected PLC configuration.
