This Xycom operator interface delivers reliable machine control and data visualization capabilities. The Xycom 2005 97958 features a high-contrast display for clear process status indication. Its rugged design ensures dependable operation in demanding production environments. This unit suits packaging, assembly, and material handling applications.

Display and Physical Specifications

This interface incorporates a 5.7-inch monochrome LCD with 320 x 240 pixel resolution. The display area measures 115 mm by 86 mm for effective viewing. Its overall dimensions reach 180 mm in width and 130 mm in height. The depth measures 65 mm behind the mounting surface. This unit weighs approximately 1.5 kilograms for stable panel installation. The Xycom 2005 97958 includes a resistive touchscreen for intuitive operator input. Twelve membrane keys provide direct access to frequently used functions.

Electrical Specifications and Interface Options

This interface draws a nominal current of 300 mA from a 24 V DC supply. Peak inrush current reaches 1.5 A for approximately 20 milliseconds during startup. The device consumes about 7 W of power during normal continuous operation. The interface provides one RS-232 port for programming and host communication. A second RS-422/485 port supports multi-drop network connections. The Xycom 2005 97958 includes a 10/100 Mbit/s Ethernet port for network integration. The unit features 4 MB of flash memory for application storage. An internal 220 µF capacitor provides energy storage for brief power interruptions.

Environmental Ratings and Mounting Details

Operating temperatures range from 0°C to 50°C for consistent performance. Storage temperatures extend from -20°C to 70°C without causing damage. Relative humidity tolerance reaches 85% with no condensation forming on surfaces. The front panel meets NEMA 4 and IP65 protection against dust and water jets. The Xycom 2005 97958 includes an integrated heater for cold-start operation below 5°C. Mount this panel using the provided brackets for a secure installation.

Detailed Specification Table

Application and Installation Guidelines

Install this interface in a clean, vibration-free location on the machine front. Cut a 160 mm x 110 mm opening in the control desk panel. Insert the unit from the front and secure it using the provided brackets. Connect the communication cables before applying power to the unit. The Xycom 2005 97958 supports configuration via the manufacturer’s software tools. Use the membrane keys for frequently performed tasks like start and stop. Clean the touchscreen surface with a soft, damp cloth regularly. Verify the communication settings match the connected PLC configuration.
