Technical Specifications and Construction Details
The Triconex 4000098-510 cable assembly serves as a critical interconnection component within Triconex safety instrumented systems . This shielded cable establishes reliable signal transmission between control modules and terminal panels . Its high-purity copper conductors with braided shielding provide superior protection against EMI and RFI . The assembly’s robust construction ensures consistent performance in demanding industrial environments.
| Parameter | Specification |
|---|---|
| Manufacturer | Triconex (Schneider Electric / Invensys) |
| Model Number | 4000098-510 |
| Product Type | Cable Assembly / Terminal Panel Cable |
| Cable Length | 2 meters (standard) ; 10 feet |
| Conductor Size | 16 AWG |
| Maximum Current | 5A |
| Voltage Rating | 300V AC/DC to 1200V |
| Conductor Material | High-purity copper |
| Shielding | Braided shield (EMI/RFI protection) |
| Capacitance | ~45 pF/m |
| DC Resistance | ~0.6 Ω/km |
| Dielectric Test Voltage | 2500V |
| Impedance | ~100Ω |
| Operating Temperature | -50°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Weight | 0.39 kg to 0.8 kg |
| Jacket Material | Flame-retardant, oil and chemical resistant |
| Compliance | UL, CSA, CE ; RoHS |
Functional Capabilities
The 4000098-510 establishes a dependable physical link between Triconex I/O modules and field termination assemblies . Its shielding effectiveness above 85 dB minimizes crosstalk and electromagnetic interference in dense control panels . The low capacitance design preserves signal fidelity for both digital and analog transmission across extended runs . This cable also supports the Triple Modular Redundancy (TMR) architecture by providing independent signal paths for enhanced fault tolerance .
Application Scenarios
This cable assembly suits critical safety applications in oil and gas, petrochemical, and power generation industries . It integrates seamlessly with Triconex 3000 series I/O modules and 4000 series communication modules . The Triconex 4000098-510 also connects external termination panels (ETP) and junction boxes within ESD and fire & gas systems . Its wide temperature range enables deployment in both cold storage and hot plant environments .
Details
| Weight | 2.85 kg |
|---|---|
| Dimensions | 41.2 × 17.8 × 6.2 mm |
