Core Specifications of the Communication Module

The 6GK1541-2BA00 belongs to the Siemens SIMATIC NET family of communication modules. This interface card links SIMATIC S5 controllers to industrial Ethernet networks. Moreover, it supports data exchange between legacy PLCs and modern supervisory systems.

Each module occupies a single slot in the S5 central rack. Additionally, the unit weighs roughly 0.50 kg with its front connector installed. The front panel measures 20 mm in width and 130 mm in height, while the 2BA00 suffix defines the interface and firmware configuration.

Interface and Mounting Details

The 6GK1541-2BA00 slides into the S5 central rack and connects to the backplane bus. Consequently, technicians complete installation without external power wiring. This module communicates through a 15-pin D-sub Ethernet port. Therefore, it integrates S5 controllers into plant-wide networks.

A front diagnostic LED shows link and activity status. Meanwhile, the compact housing fits standard S5 rack layouts.

Performance and Application Notes

Plant engineers deploy the 6GK1541-2BA00 to bridge legacy controllers and modern SCADA systems. Furthermore, the module handles 10 Mbps Ethernet traffic with stable throughput. Its onboard firmware manages protocol conversion without host CPU overhead. Meanwhile, the backplane interface keeps data transfer synchronized with the rack.

The module stores no energy internally, since it draws power from the backplane. As a result, it adds minimal load to the S5 power budget.
