Durable Operator Interface for Industrial Use

This membrane keypad panel provides a robust and reliable operator interface for industrial equipment. The 6FM1496-4KB00 offers tactile key feedback for accurate and confident operator inputs. It also protects the underlying electronics from dust, moisture, and contaminants. The panel uses a customizable overlay for various application-specific labels. Its slim profile allows easy integration into machine control consoles and operator stations.

Technical Specifications and Physical Attributes

The 6FM1496-4KB00 features a 48-key membrane keypad with a durable polyester construction. It provides a standard 25-pin Sub-D connector for straightforward system integration. The keypad also uses a matrix configuration, supporting up to 96 key inputs for comprehensive control. It measures approximately 325 mm in width, 168 mm in height, and 8 mm in depth. The panel weighs roughly 0.72 kg. Furthermore, the 6FM1496-4KB00 operates within a temperature range of 0 °C to 50 °C. Its IP65 front protection ensures resistance to dust and water jets.

Installation and Application Guidance

This keypad panel serves as a primary input device for machine tools and process control systems. First, mount the 6FM1496-4KB00 securely into the designated panel cutout using the mounting clips. Then, connect the 25-pin Sub-D cable to the corresponding controller or interface module. Always verify proper grounding before energizing the system. The robust membrane construction withstands repeated actuations in demanding industrial environments. Its legacy design makes it suitable for upgrading or maintaining older control systems.
