This display module offers a dedicated visual interface for Siemens automation systems. It provides real-time process data visualization for effective operator supervision. We designed the Siemens 6FM1470-3BA25 for integration with SIMATIC S5 and S7 platforms. This module presents critical parameters in an easy-to-read format. It enables immediate status awareness for plant personnel. Therefore, operators can respond quickly to changing process conditions.
Physical Configuration and Mounting Specifications
The Siemens 6FM1470-3BA25 features a compact panel-mount design for control cabinet installation. Its dimensions measure 138.0 mm in width, 68.0 mm in height, and 43.0 mm in depth. The module weighs approximately 0.35 kilograms for straightforward mounting procedures. This unit fits standard front panel cutouts with included hardware. It connects to the controller via a rear-panel interface connector. The display offers a bright, high-contrast LCD for clear visibility.
Display Characteristics and User Interface
This display module presents alphanumeric information across multiple lines. It shows up to 20 characters per line for comprehensive data presentation. The Siemens 6FM1470-3BA25 incorporates a backlight for low-light viewing conditions. It offers adjustable contrast settings for operator preference. The module includes tactile pushbuttons for menu navigation and parameter adjustment. It supports both local and remote control modes for application flexibility. Consequently, this provides versatile operator interaction capabilities.
Detailed Technical Specifications
We outline the module’s comprehensive technical parameters and operational details below.
| Specification | Detail |
|---|---|
| Part Number | Siemens 6FM1470-3BA25 |
| Product Category | Display Module |
| Dimensions (W x H x D) | 138.0 mm x 68.0 mm x 43.0 mm |
| Module Weight | Approximately 0.35 kg (0.77 lbs) |
| Display Type | LCD alphanumeric |
| Display Lines | 4 lines |
| Characters Per Line | 20 characters |
| Character Format | 5 x 7 dot matrix |
| Backlight | LED, green |
| Contrast Control | Adjustable via potentiometer |
| User Controls | 6 tactile pushbuttons (membrane) |
| Control Functions | Menu navigation, value adjustment, mode selection |
| Interface Connector | 15-pin D-sub (rear panel) |
| Communication Protocol | Proprietary Siemens interface |
| Power Supply | 24 VDC nominal (18 to 30 VDC range) |
| Power Consumption | 2.0 W typical |
| Display Update Rate | 500 ms typical |
| Memory | Internal EEPROM for configuration storage |
| Diagnostic Functions | Self-test on power-up |
| Mounting Style | Front panel mount (cutout: 130.0 mm x 60.0 mm) |
| Ingress Protection | IP65 (front face) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Compatibility | SIMATIC S5, S7 systems |
| Compliance | CE, RoHS |
Details
| Weight | 0.35 kg |
|---|---|
| Dimensions | 138 × 68 × 43 mm |
