Processing Unit Overview
The Siemens 6ES7315-1AF03-0AB0 serves as a mid-range CPU module for the SIMATIC S7-300 programmable logic controller family. This processor handles complex automation tasks with its integrated multitasking operating system. It executes user programs efficiently while managing all connected I/O modules. Many manufacturing systems rely on this CPU for reliable production control.
Technical Specifications
The 6ES7315-1AF03-0AB0 measures 125 mm in height and 40 mm in width. Its compact form factor fits standard S7-300 rail mounting systems. The module weighs approximately 0.3 kilograms. It draws 850 mA from the 24V DC power supply.
| Parameter | Specification |
|---|---|
| Model | 6ES7315-1AF03-0AB0 |
| Product Type | CPU 315 Processor |
| Dimensions | 125 mm x 40 mm |
| Weight | ~0.3 kg |
| Supply Voltage | 24V DC |
| Current Draw | 850 mA (typical) |
| Work Memory | 128 KB (program) + 128 KB (data) |
| Load Memory | 512 KB Flash (integrated) |
| Processing Speed | 0.3 ms per 1K instructions |
| Bit Operations | 0.3 μs execution time |
| Interfaces | 1 x MPI/DP (9-pin D-sub), 1 x PROFIBUS DP (optional) |
| On-board Components | 1 x processor, 4 x RAM chips, 1 x Flash chip |
| Energy Storage | 220 μF backup capacitor |
| LED Indicators | 5 x Status (RUN, STOP, BUSF, SF, MAINT) |
| Operating Temp. | 0°C to +60°C |
Processing Architecture and Memory
This CPU integrates a powerful 32-bit processor with dedicated program and data memory. The work memory splits into 128 KB for program logic and 128 KB for data storage. A built-in 512 KB Flash memory retains the user program even without power. The processor executes bit operations in just 0.3 microseconds. The CPU handles up to 1024 digital and 128 analog I/O points. A 220 μF capacitor maintains real-time clock and retentive data during short power dips.
Communication Interfaces
The Siemens 6ES7315-1AF03-0AB0 features a 9-pin D-sub connector for the MPI/DP interface. This port supports programming, commissioning, and HMI connectivity. An optional second PROFIBUS DP port enables distributed I/O configurations. The module uses the PROFIBUS protocol for high-speed data exchange. Standard RS-485 electrical characteristics ensure robust industrial communication. The CPU can act as both master and slave on the network.
Installation and System Integration
Installing the 6ES7315-1AF03-0AB0 requires one slot in the S7-300 rail. The module clips onto the DIN rail and connects via the backplane bus. You load the user program through the MPI port using STEP 7 software. The CPU automatically configures the I/O modules during startup. It operates reliably across a 0°C to 60°C temperature range. The module includes a removable memory card slot for firmware updates. Five status LEDs provide comprehensive diagnostic information.
Reliability and Operational Features
The Siemens 6ES7315-1AF03-0AB0 delivers consistent performance in 24/7 industrial environments. Its retentive data storage protects critical values during power interruptions. The CPU includes a hardware watchdog timer for failsafe monitoring. Periodic diagnostics check memory integrity and communication health. Replacing the module requires only a power cycle and program reload.
Details
| Weight | 0.3 kg |
|---|---|
| Dimensions | 125 × 40 × 10 mm |
