The 6ES5247-1AA11 belongs to the Siemens SIMATIC S5 family of automation components. This stepper motor positioning module delivers accurate motion control for industrial applications. Engineers value its robust design and reliable performance in demanding environments.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | Stepper Motor Positioning Module |
| Compatibility | Siemens SIMATIC S5 PLC Systems |
| Module Width | Single-width compact housing |
| Weight | Approximately 0.5 kg |
| Interface Type | PLC backplane bus connection |
| Axis Control | Single-axis stepper motor control |
| Pulse Output | Step and direction signals |
| Power Supply | Via S5 backplane power rail |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Mounting Style | Standard S5 rack mounting |
Functional Overview
This module generates precise pulse trains for stepper motor drivers. Consequently, it achieves smooth acceleration and deceleration profiles during positioning tasks. The 6ES5247-1AA11 supports both incremental and absolute positioning modes. Therefore, system integrators can implement complex motion sequences efficiently.
Integration and Compatibility
The 6ES5247-1AA11 plugs directly into standard S5 mounting racks. Additionally, it communicates with the CPU through the backplane bus. No external wiring exists beyond the motor driver connections. This design simplifies commissioning and reduces installation time significantly. Furthermore, the module maintains signal integrity across long cable runs.
Typical Applications
Manufacturers deploy this module in packaging, printing, and material handling systems. Moreover, it suits CNC positioning tasks requiring moderate torque output. The 6ES5247-1AA11 excels where repeatable movement matters most.
Details
| Weight | 0.72 kg |
|---|---|
| Dimensions | 325 × 168 × 8 mm |
