Technical Overview of the Processor Module
The Siemens 6DD1601-0AE0 functions as a high-performance processor module for the SIMADYN D drive control system. This module executes real-time control algorithms for complex drive and motion applications. It handles high-speed data processing and communication with connected power converters. The design supports multi-tasking operation for demanding automation tasks.
Key Technical Specifications
This section details the precise parameters for the Siemens 6DD1601-0AE0 processor module. Use these figures to verify compatibility with your SIMADYN D system.
| Parameter | Specification |
|---|---|
| Part Number | 6DD1601-0AE0 |
| Type | Processor Module |
| Product Family | SIMADYN D |
| Processor Type | 32-bit (proprietary) |
| User Memory | 1 Mbyte (RAM) |
| Program Memory | 2 Mbytes (Flash EPROM) |
| Processing Speed | Approx. 10 ms for complete task cycle |
| Communication Interfaces | Serial, fiber optic, PROFIBUS DP |
| I/O Capacity | Configurable via expansion modules |
| Diagnostics | Integrated self-test and status LEDs |
| Dimensions (W x H x D) | Approx. 250 x 30 x 160 mm |
| Weight | Approx. 1.5 kg |
| Compatibility | SIMADYN D drive control systems |
Application and System Integration
This processor module mounts directly into the SIMADYN D rack. It executes control logic for high-performance drive applications. The Siemens 6DD1601-0AE0 communicates with power converters via fiber optic links. Its PROFIBUS DP interface connects to supervisory control systems.
Reliability and Performance Characteristics
The module handles complex arithmetic with deterministic cycle times. Its large memory accommodates extensive control programs and data. The robust construction ensures reliable operation in industrial environments. Engineers trust the Siemens 6DD1601-0AE0 for demanding drive control applications.
Details
| Weight | 1.2 kg |
|---|---|
| Dimensions | 50 × 290 × 217 mm |
