Intuitive HMI Interface for Industrial Control Systems
The 6BK1100-0BA01-1AA0 operator panel provides a user-friendly interface for monitoring and controlling industrial processes. This panel belongs to the Simatic HMI product family and delivers reliable visual management . It features a monochrome LC display with 240 x 64 pixel resolution for clear process data presentation. Furthermore, this unit includes 20 function keys for convenient access to critical operations.
Display and Input Specifications
The 6BK1100-0BA01-1AA0 utilizes a high-contrast display with effective backlighting for visibility in diverse lighting conditions. It includes a numeric keypad and configurable function keys for efficient plant navigation. The panel also features status LEDs that indicate operational states at a glance. Users can navigate menus easily using the tactile buttons and logical menu structure.
Connectivity and Configuration
This panel connects to Siemens controllers via an RS-232 interface for straightforward data exchange. The 6BK1100-0BA01-1AA0 supports remote monitoring through a PC connection and features a memory slot for storing project data. Additionally, this unit uses a 24 V DC power supply and includes a clock for time-stamping events.
Physical Dimensions and Environmental Ratings
Weighing approximately 0.7 kg, this operator panel offers a compact and sturdy design . It operates reliably from 0°C to 50°C and stores safely without damage . This unit measures 14.2 cm x 19.5 cm x 5.8 cm, making it suitable for tight control panels . It also features an IP65 rating, offering robust protection against dust and water ingress.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Siemens |
| Product Line | Simatic HMI |
| Model | 6BK1100-0BA01-1AA0 |
| Product Type | Operator Panel |
| Display | Monochrome LC Display |
| Resolution | 240 x 64 pixels |
| Input Method | Keypad (20 function keys, numeric keys) |
| Communication Ports | RS-232, PC port |
| Power Supply | 24 V DC |
| Memory | Memory slot for project data |
| Real-time Clock | Yes (battery-backed) |
| Weight | 0.7 kg |
| Dimensions (H x W x D) | 14.2 x 19.5 x 5.8 cm |
| Operating Temperature | 0°C to +50°C |
| Protection Rating | IP65 (front panel) |
| Certifications | CE, UL, CSA |
Details
| Weight | 1.2 kg |
|---|---|
| Dimensions | 50 × 290 × 217 mm |
