This operator panel provides local monitoring and control for automation systems. The Siemens 6AV8100-0BB00-0AA1 belongs to the SIMATIC HMI KTP400 family. You can display process values and system status on its color touchscreen. Users can acknowledge alarms and modify setpoints through the intuitive interface.
Physical Dimensions and Hardware Layout
The Siemens 6AV8100-0BB00-0AA1 measures 13.0 cm in overall width. Its total height reaches 10.0 cm including the mounting bezel. This operator panel weighs approximately 0.45 kg. A plastic housing with metal backplate provides durability. The panel fits standard 118 x 88 mm cutouts for flush mounting.
Display and Touch Specifications
This panel features a 4.3-inch widescreen TFT color display. The Siemens 6AV8100-0BB00-0AA1 provides 480 x 272 pixel resolution. The analog resistive touchscreen registers inputs from fingers or stylus. A white LED backlight ensures clear visibility in dim control rooms. Four function keys flank the display for quick access.
| Parameter | Specification |
|---|---|
| Product Type | Touch operator panel |
| Product Family | SIMATIC HMI KTP400 Basic |
| Display Size | 4.3 inches diagonal |
| Display Type | TFT color LCD |
| Resolution | 480 x 272 pixels (WQVGA) |
| Color Depth | 65,536 colors |
| Touchscreen Type | Analog resistive |
| Function Keys | 4 (user-programmable) |
| Communication Ports | 1x PROFINET (RJ45), 1x RS‑485/RS‑422 |
| Supported Protocols | PROFINET IO, MPI, PROFIBUS DP |
| Baud Rate | Up to 12 Mbps (PROFIBUS) |
| Dimensions (W x H x D) | 130 mm x 100 mm x 45 mm |
| Cutout Size | 118 mm x 88 mm |
| Weight | 0.45 kg (0.99 lbs) |
| Supply Voltage | 24V DC ±20% |
| Current Draw | 250 mA typical |
| Power Dissipation | 6.0 W max |
| Internal Energy Storage | 100 µF capacitor for data retention |
| Backup Memory | 512 kB EEPROM (non‑volatile) |
| Backlight Type | White LED |
| Backlight Life | 50,000 hours typical |
| Front Protection | IP65 (when mounted) |
| Rear Protection | IP20 |
| Operating Temperature | 0°C to +50°C |
Energy Storage and Data Retention
Internal capacitors preserve screen data during brief power dips. The Siemens 6AV8100-0BB00-0AA1 maintains recipe data in non‑volatile EEPROM. This storage retains all parameters without battery backup. Consequently, you lose no configuration after power cycles.
Communication and PLC Compatibility
You connect this panel to Siemens PLCs via PROFINET or PROFIBUS. The Siemens 6AV8100-0BB00-0AA1 supports S7-1200, S7-1500, and S7-300 controllers. The panel acts as a PROFINET IO device on the network. Multiple panels can share the same network without additional hardware.
Configuration and Programming
You program the Siemens 6AV8100-0BB00-0AA1 using WinCC Basic software. Create screens with buttons, bar graphs, and trend displays. Download the project via the PROFINET or USB port. The panel stores the entire project in its internal flash memory. Therefore, no external storage media is necessary.
Details
| Weight | 1.2 kg |
|---|---|
| Dimensions | 50 × 290 × 217 mm |
