Product Overview
The Siemens 6AV6541-0AA05-2BC0 serves as a graphical operator interface for the Simatic HMI product family. This display panel presents process data and machine status information in a clear visual format. Factory operators rely on this unit for real-time monitoring and interactive control tasks.
Technical Specifications
This display panel features a backlit LCD screen with configurable contrast settings. The Siemens 6AV6541-0AA05-2BC0 integrates touch-sensitive functionality for intuitive screen navigation. Its slim profile allows flush mounting on control cabinet doors and operator consoles. The unit’s anti-glare coating ensures legibility even under bright workshop lighting.
| Parameter | Specification |
|---|---|
| Product Type | Display Panel / HMI Operator Interface |
| Series Compatibility | Siemens Simatic HMI (TP/OP series compatible) |
| Display Type | Backlit LCD with CCFL illumination |
| Screen Size | 5.7 inches (diagonal) |
| Resolution | 320 x 240 pixels (QVGA) |
| Display Colors | 256 colors (color version) |
| Backlight Lifetime | Minimum 50,000 hours at 25°C |
| Touch Technology | Resistive touchscreen (4-wire) |
| Dimensions (W x H x D) | 212 mm x 156 mm x 45 mm |
| Weight | Approximately 0.85 kg |
| Energy Storage | 128 KB battery-backed SRAM for screen configurations |
| Backup Battery | Lithium cell (3.6 V, replaceable) |
| Protection Rating | IP65 (front face when installed) |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +60°C |
| Mounting Method | Four clamps from rear side |
Display Performance
This panel renders graphics with sufficient clarity for numeric values and trend diagrams. The Siemens 6AV6541-0AA05-2BC0 maintains consistent brightness throughout its extended backlight lifespan. Its resistive touchscreen responds accurately to finger or stylus inputs. The display’s wide viewing angle allows multiple operators to read data simultaneously.
Configuration and Memory
Users configure this panel using Siemens ProTool or WinCC software environments. The Siemens 6AV6541-0AA05-2BC0 stores screen layouts and tag assignments in its internal memory. The battery-backed SRAM retains configuration data during power interruptions. This feature eliminates the need for repeated downloads after unexpected shutdowns.
Connectivity and Integration
This panel connects to PLC systems via serial or MPI communication interfaces. The Siemens 6AV6541-0AA05-2BC0 supports standard PROFIBUS DP for high-speed data exchange. Its integrated ports enable direct links to S5, S7, and third-party controllers.
Application Scenarios
Machine builders install this display on packaging machinery, conveyor systems, and assembly stations. Process industries deploy it for batch monitoring and recipe management tasks. The Siemens 6AV6541-0AA05-2BC0 provides a cost-effective visualization solution for medium-complexity applications.
Details
| Weight | 0.85 kg |
|---|---|
| Dimensions | 212 × 156 × 45 mm |
