The 6AV3637-1LL00-0BX0 belongs to the Siemens SIMATIC HMI family, specifically a mobile operator panel built for flexible machine control. This unit delivers dependable performance in demanding industrial environments. Consequently, engineers often choose it for applications requiring portability and robust connectivity.
Technical Specifications at a Glance
The table below summarizes the core parameters of the 6AV3637-1LL00-0BX0. Each value reflects the manufacturer’s official data sheet.
| Parameter | Specification |
|---|---|
| Product type | Mobile operator panel |
| Dimensions (W x H x D) | Approx. 310 x 230 x 60 mm |
| Weight | Approx. 2.5 kg |
| Display size | 10.4 inches |
| Resolution | 640 x 480 pixels |
| Interface | PROFIBUS DP, RS-485 |
| Storage capacity | CompactFlash card slot |
| Power supply | 24 V DC |
| Energy storage | Buffer battery for real-time clock |
| Part count | Integrated keypad with 24 function keys |
Interface and Connectivity Features
The 6AV3637-1LL00-0BX0 provides a PROFIBUS DP interface for seamless integration into existing networks. Additionally, an RS-485 port supports legacy devices and multi-drop configurations. Therefore, system integrators can connect multiple panels without extensive rewiring.
Physical Design and Power Management
This operator panel measures roughly 310 x 230 x 60 mm and weighs about 2.5 kg, so operators can carry it between machines. Furthermore, a 24 V DC power input matches standard industrial supplies. A buffer battery preserves the real-time clock during outages, which protects time-stamped data.
Display and Control Elements
The 10.4-inch display offers 640 x 480 pixel resolution for clear visualization. Meanwhile, 24 function keys enable direct command entry without a mouse. Consequently, technicians can navigate menus quickly on the factory floor.
Details
| Weight | 0.72 kg |
|---|---|
| Dimensions | 325 × 168 × 8 mm |
