Product Overview
The Siemens 6AV3607-1JC20-0AX1 Operator Panel provides efficient machine operation and visualization functions for industrial automation applications. Moreover, the panel enables operators to monitor processes, adjust parameters, and interact with control systems conveniently. Its compact design supports flexible installation in industrial cabinets and machine control stations. Additionally, the reliable interface improves production efficiency while maintaining stable performance during continuous operation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model | 6AV3607-1JC20-0AX1 |
| Product Category | Operator Panel |
| Product Series | SIMATIC HMI |
| Display Type | LCD Display |
| Display Size | Approx. 5.7 inches |
| Resolution | 320 × 240 Pixels |
| Operator Interface | Function Keys and Display Controls |
| Communication Interface | MPI / PROFIBUS DP |
| Number of Function Keys | 20 Keys |
| Power Supply | 24 V DC |
| Power Consumption | Approx. 10 W |
| Mounting Method | Panel-mounted |
| Dimensions | Approx. 212 × 156 × 55 mm |
| Weight | Approx. 1.0 kg |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +60°C |
Key Features
The 6AV3607-1JC20-0AX1 delivers clear machine visualization and convenient operator control for industrial production environments. Furthermore, the integrated display provides essential process information, alarms, and operating parameters for efficient machine management. Engineers can connect the panel with compatible Siemens PLC systems through established communication networks. Consequently, operators gain faster access to machine data while improving overall production control.
The panel measures approximately 212 × 156 × 55 mm and weighs around 1.0 kg for practical installation. Additionally, the 5.7-inch LCD display presents process information with a resolution of 320 × 240 pixels. The integrated function keys allow direct operation without requiring external input devices. Therefore, users can perform routine adjustments quickly while maintaining reliable machine interaction.
Typical Applications
The 6AV3607-1JC20-0AX1 supports packaging machinery, manufacturing equipment, process automation systems, and production line control applications. Meanwhile, engineers use this operator panel for machine monitoring, parameter adjustment, alarm handling, and operator guidance. Its compact structure also makes it suitable for space-limited industrial control environments.
Advantages
- Provides clear industrial machine visualization.
- Supports direct operator control through integrated function keys.
- Communicates efficiently with Siemens PLC systems.
- Compact dimensions simplify panel installation.
- 24 V DC power supply matches industrial standards.
- Reduces dependence on external operating equipment.
- Improves machine operation efficiency and user convenience.
Technical Highlights
| Feature | Benefit |
|---|---|
| 5.7-inch LCD Display | Provides clear process visualization |
| 320 × 240 Resolution | Delivers readable operating information |
| 20 Function Keys | Enables direct machine control |
| MPI / PROFIBUS DP Interface | Supports reliable PLC communication |
| Approx. 1.0 kg Weight | Simplifies installation and maintenance |
| 24 V DC Supply | Fits standard automation environments |
Details
| Weight | 1.2 kg |
|---|---|
| Dimensions | 50 × 290 × 217 mm |
