Reliable HMI Interface for SIMATIC Systems

This operator panel provides a robust human-machine interface for SIMATIC-based automation systems. The 6AV3530-1RR01 features a clear LCD display protected by durable mineral glass. It uses tactile keys for direct operator input without a touchscreen or direct keypad. The panel belongs to the SIMATIC HMI family and serves as the OP30/A model. Its compact design fits standard control cabinets with minimal space requirements.

Technical Specifications and Physical Attributes

The 6AV3530-1RR01 measures 381 mm in length, 279 mm in width, and 127 mm in height . It weighs approximately 4.2 kg, making it suitable for fixed panel mounting . The device operates within an ambient temperature range of 0 °C to 40 °C. Moreover, it tolerates relative humidity up to 80% without condensation . The mineral glass front offers excellent scratch resistance and long-term visibility. This panel comes without direct keys, relying instead on its standard keypad layout for all operator interactions.

Installation and Application Guidance

This operator panel integrates seamlessly with PLC systems and process automation equipment. First, mount the 6AV3530-1RR01 securely into the designated panel cutout using the provided mounting clips. Then, connect the communication cable to the SIMATIC PLC or controller for data exchange. Always ensure proper grounding to minimize electromagnetic interference. The panel excels in machine control, manufacturing automation, and process monitoring applications . Its durable construction ensures reliable performance in demanding industrial environments.
