This extension rack adds six additional slots to your existing Premium PLC system. It supports a broader range of I/O modules for complex control strategies. The unit integrates seamlessly with the TSX P57 processor series. Users can scale their automation infrastructure without replacing the main backplane.

Mechanical Structure and Physical Specifications

This rack features a rugged steel chassis for reliable industrial mounting. The unit measures 265 mm in width and 146 mm in height. Its depth reaches 140 mm for standard cabinet compatibility. The total weight comes to approximately 1.2 kg without attached modules. A dedicated grounding terminal ensures proper electrical safety during operation.

Extension Capabilities and System Interconnection

This rack connects to the main Premium station via a shielded bus extension cable. It supports a maximum extension distance of 10 meters between racks. The internal backplane carries both data and power signals to all six slots. Each slot accepts standard Premium I/O, counter, or communication modules. This architecture enables distributed control for large-scale production lines. Consequently, engineers can position I/O closer to field devices for better signal integrity.

Power Distribution and Electrical Characteristics

The TSXRKY6EX receives its operating voltage directly from the main power supply module. It provides a total backplane current capacity of 1.5 A at 5 V DC for all connected modules. An additional 0.5 A at 24 V DC supports output modules and sensor supplies. The rack includes built-in overcurrent protection for each slot. This feature safeguards downstream modules from short-circuit events. Moreover, the unit draws minimal power during idle states to reduce energy costs.

Installation Flexibility and Environmental Tolerance

This extension rack supports both DIN rail and screw mounting options for versatile placement. Its compact form factor fits within most standard IP20 control enclosures. The operating temperature ranges from 0 °C to 60 °C for reliable performance. It withstands humidity levels between 10% and 95% without condensation. Furthermore, the rack resists vibration up to 0.75 g from 10 to 57 Hz. These characteristics make it suitable for automotive and material handling applications.
