Reliable 36W Power Delivery for Modicon Premium Racks
The TSXPSY3610 power supply module provides dependable 24 V DC power for Modicon Premium automation platforms . This compact unit delivers up to 36 W of total output power with an impressive efficiency rating of 85% or higher . It offers a 1.5 A current output capacity, ensuring stable power for standard rack configurations . Furthermore, the module operates within a 19.2 to 30 V DC input voltage range, giving it excellent tolerance for fluctuating supply conditions .
Comprehensive Protection for Critical Systems
The TSXPSY3610 integrates multiple protective features to safeguard both the module and connected equipment. It includes overcurrent, overvoltage, and short-circuit protection across its secondary circuits . Moreover, the unit features a built-in alarm relay that provides status monitoring via a green OK LED . The module also accommodates a backup battery, which preserves processor memory during power outages . A reset button on the front panel enables quick application hot starts when necessary .
Physical Characteristics and Environmental Ratings
This double-format module weighs 0.78 kg (1.72 lbs) and meets IP20 protection standards . It operates reliably across a 0°C to 60°C temperature range and stores safely from -25°C to 70°C . The unit also tolerates up to 95% relative humidity without condensation, ensuring dependable performance in diverse industrial environments . Additionally, it carries CE marking and holds UL 508 certification alongside multiple marine approvals from DNV, ABS, BV, and LR .
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Line | Modicon Premium |
| Module Type | Power Supply Module |
| Input Voltage | 24 V DC (19.2 to 30 V) |
| Input Current | ≤ 2700 mA at 24 V |
| Total Output Power | 50 W |
| 5 V DC Output | 7 A, 35 W |
| 24 V DC Output | 0.6 A, 19 W |
| Efficiency | ≥ 85% |
| Protection Type | Overcurrent, Overvoltage, Short-circuit |
| Inrush Current | 150 A at 24 V |
| Immunity to Microbreaks | ≤ 1 ms |
| Dielectric Strength | 2000 V primary/earth, 2000 V primary/secondary |
| Product Weight | 0.78 kg (1.72 lbs) |
| Dimensions (LxWxH) | 15.0 x 8.0 x 13.5 cm |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -25°C to 70°C |
| Relative Humidity | 10 to 95% (operation), 5 to 95% (storage) |
| IP Degree of Protection | IP20 |
| Module Format | Double |
| Certifications | CE, UL 508, CSA, DNV, ABS, BV, GL, LR, RINA, RMRS |
| Country of Origin | France |
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
