This processor module executes user logic for Schneider Modicon Premium PLC systems. It manages real-time control tasks and communication with field devices. Therefore, this component suits complex automation in manufacturing and process industries.

Physical Dimensions and Weight Specifications

The Schneider TSXP57554 occupies one standard slot in the Premium rack. Its housing measures 220 mm in depth for backplane connectivity. The module weighs approximately 0.62 kg for straightforward handling. Consequently, technicians can install this unit without additional rack reinforcement.

Interface Types and Connection Layout

The Schneider TSXP57554 provides one RS-232 port for programming access. A second RS-485 interface supports Modbus communication with field devices. The front panel carries a built-in Ethernet port for plant network connectivity. Hence, users can program and monitor this CPU remotely.

Component Count and Onboard Memory

This processor module contains one main board with a 32-bit RISC processor. The board holds 512 KB of battery-backed RAM for user programs. You will also find 1 MB of flash memory for non-volatile storage. An onboard real-time clock maintains schedule data during power cycles.

Energy Storage and Power Consumption

The Schneider TSXP57554 draws 350 mA from the 5V backplane supply. A lithium battery retains RAM data for 1,000 days without external power. This battery maintains user programs during extended facility shutdowns. Therefore, the CPU eliminates the need for frequent reprogramming after outages.

Processing Speed and I/O Capacity

The processor executes 0.1 microseconds per basic logic instruction. It handles up to 2048 digital I/O points within a single scan. Users can store up to 4096 function blocks in the flash memory. This capacity supports complex automation for large production lines.
