This double format processor delivers powerful control capabilities for large-scale Modicon Premium automation applications. It executes complex PL7 programs with exceptional speed and processing efficiency. We engineered the Schneider TSXP573623AM as a high-performance CPU for demanding industrial environments. This processor manages extensive I/O configurations and sophisticated control strategies. It ensures deterministic performance for time-critical process operations. Therefore, your Premium system achieves optimal productivity and operational reliability.
Physical Configuration and System Integration
The Schneider TSXP573623AM features a double format module occupying two rack slots. Its dimensions measure 140.0 mm in height, 98.0 mm in width, and 150.0 mm in depth. The processor weighs approximately 0.9 kilograms for secure installation within the Premium rack. This unit connects to the backplane via the standard Modicon Premium bus. It supports both local and remote I/O configurations for system scalability. The processor provides comprehensive diagnostic LEDs for operational monitoring.
Processing Power and Memory Specifications
This processor operates with a high-speed 32-bit microprocessor architecture. It delivers rapid instruction execution for complex automation tasks. The Schneider TSXP573623AM provides substantial memory capacity for extensive user programs. It includes integrated RAM with battery backup for reliable data retention. The module supports PL7 programming with all language elements. It features a built-in real-time clock for scheduled control operations. Consequently, this offers exceptional processing capability for sophisticated automation applications.
Detailed Technical Specifications and Interface Details
We present the processor’s comprehensive technical parameters and operational capabilities below.
| Specification | Detail |
|---|---|
| Part Number | Schneider TSXP573623AM |
| Product Category | Double Format PL7 Processor |
| Dimensions (H x W x D) | 140.0 mm x 98.0 mm x 150.0 mm |
| Processor Weight | Approximately 0.9 kg (1.98 lbs) |
| Rack Slot Requirement | 2 slots (Modicon Premium) |
| CPU Architecture | 32-bit microprocessor |
| Program Memory | 192 KB RAM (battery-backed) |
| Data Memory | 64 KB RAM |
| Programming Software | PL7 Pro |
| Programming Languages | Ladder, function block, structured text, SFC |
| Bit Instruction Time | 0.14 µs per bit operation |
| Word Instruction Time | 0.56 µs per 16-bit operation |
| Maximum Digital I/O | 1024 points |
| Maximum Analog I/O | 128 channels |
| Maximum Remote I/O | Up to 8 remote drops |
| Integrated Functions | Real-time clock, watchdog timer, hardware interrupts |
| Serial Interface 1 | RS-232 (programming/termination) |
| Serial Interface 2 | RS-485 (Modbus) |
| Additional Interface | PCMCIA slot for memory expansion |
| Supported Protocols | Modbus RTU, Modbus Plus, Unitelway |
| Diagnostic Indicators | RUN, I/O, ERR, BAT, TER status LEDs |
| Backplane Interface | Modicon Premium bus connector |
| Power Supply | 5 VDC from backplane |
| Power Consumption | 4.5 W typical |
| Battery Type | Lithium 3.0 V (replaceable) |
| Battery Backup Duration | Approximately 1 year minimum |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -25°C to 70°C (-13°F to 158°F) |
| Compliance | CE, UL, CSA, RoHS |
Details
| Weight | 0.9 kg |
|---|---|
| Dimensions | 140 × 98 × 150 mm |
