The Schneider TSXP5720 executes control logic inside Modicon Premium automation platforms. Engineers select this processor when demanding applications require fast scan times and expanded memory. Consequently, the unit delivers deterministic performance across continuous plant operations.

Physical Dimensions and Weight Data

Cabinet space often limits how technicians arrange processor hardware inside control racks. Therefore, this processor keeps a compact profile while supporting full logic capacity. It weighs roughly 0.9 kg and measures 250 mm in length. Additionally, its width spans 100 mm with a depth of 120 mm.

Interfaces and Connectivity Features

Reliable computation depends on secure links between the processor and connected I/O modules. The unit provides backplane connectors for critical data paths. Furthermore, front-panel LEDs let technicians verify processor and fault status instantly. The design supports hot-swap replacement without rewiring field connections.

Component Count and Energy Storage

Internal architecture shapes both diagnostic coverage and service life. This processor carries more than 300 discrete components across its processing stages. Moreover, a lithium battery retains configuration data for up to 90 days. This storage protects non-volatile memory whenever plant power drops.

Key Technical Specifications

Processing Performance and Compliance

Fast scan cycles directly influence overall control loop accuracy. The processor completes typical logic scans within 10 ms. Meanwhile, isolation voltage reaches 500 VDC between backplane wiring and internal circuits. Diagnostic coverage exceeds 99%, which strengthens fault detection.

Industrial sites also demand strict safety certifications before deployment. The processor complies with IEC and UL standards for industrial control equipment. In addition, it meets CE requirements for electromagnetic compatibility. These credentials support dependable operation in harsh plant environments.
