Core Capabilities of the TSXDSZ08T2
This discrete output module provides eight relay channels for driving various field actuators and loads. The TSXDSZ08T2 supports switching voltages up to 250 VAC or 125 VDC for versatile applications. Each relay contact handles a continuous current of 2 A, making it suitable for solenoid valves and indicator lamps. Additionally, the module offers mechanical isolation between the internal logic and the output circuits. This isolation ensures safe operation even under fault conditions. The unit fits seamlessly into the Modicon Premium platform, ensuring straightforward integration with your existing system architecture.
Performance Specifications and Physical Attributes
The TSXDSZ08T2 operates reliably across a temperature range from 0 °C to 60 °C. It measures 102 mm in height and 99 mm in depth, matching the standard form factor for this series. The module weighs approximately 0.35 kg, adding modest weight to the overall rack configuration. You can mount this output module on a DIN rail or directly onto the Premium backplane. For wiring convenience, the TSXDSZ08T2 features removable terminal blocks for field connections. The relay response time reaches up to 10 ms for rapid output activation. Consequently, this module provides dependable switching performance for demanding industrial tasks.
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | Discrete Output Module |
| Part Number | TSXDSZ08T2 |
| Number of Outputs | 8 (Relay) |
| Switching Voltage | 250 VAC / 125 VDC |
| Contact Current | 2 A per channel |
| Response Time | ≤ 10 ms |
| Isolation | Mechanical (logic to field) |
| Dimensions (H x D) | 102 mm x 99 mm |
| Weight | Approx. 0.35 kg (0.77 lb) |
| Operating Temp. | 0 °C to 60 °C |
| Mounting | DIN Rail or Backplane |
Installation and Wiring Recommendations
This relay module interfaces directly with AC or DC loads in your control system. First, disconnect all power sources before inserting the TSXDSZ08T2 into the rack. Then, wire the load circuits to the appropriate output terminals using the removable connectors. For inductive loads like relays or contactors, always install flyback diodes or snubber circuits. These components protect the relay contacts from voltage spikes during switching events. Furthermore, maintain proper clearance between high-voltage and low-voltage wiring. The TSXDSZ08T2 conforms to the IEC 61131-2 standard, ensuring reliable operation in industrial environments.
Details
| Weight | 0.25 kg |
|---|---|
| Dimensions | 130 × 100 × 20 mm |
