The Schneider TSXAEY1600 Analog Input Module delivers accurate analog signal acquisition for industrial automation, process control, and PLC-based monitoring systems. Its compact design, stable electrical performance, and high measurement precision help engineers collect reliable field data while improving overall control efficiency.
Product Overview
The TSXAEY1600 converts analog signals from field instruments into precise digital values for industrial controllers and automation platforms. Moreover, the module maintains stable signal transmission during continuous operation, ensuring consistent process monitoring across demanding production environments. Its rugged construction also supports long-term reliability while reducing routine maintenance requirements.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Schneider Electric |
| Model | TSXAEY1600 |
| Product Category | Analog Input Module |
| Input Channels | 16 Analog Input Channels |
| Input Signal Type | Voltage and Current Inputs |
| Input Resolution | 16-bit A/D Conversion |
| Power Supply | Internal PLC Backplane Supply |
| Communication Interface | TSX PLC Backplane Interface |
| Isolation | Channel-to-System Electrical Isolation |
| Mounting Method | Rack Installation |
| Dimensions | Approximately 235 × 160 × 35 mm |
| Weight | Approximately 0.45 kg |
| Internal Components | High-density Industrial PCB with Precision Signal Circuits |
| Energy Storage | Integrated Filter Capacitors for Voltage Stabilization |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95%, Non-condensing |
Performance Advantages
The Schneider TSXAEY1600 captures analog signals with excellent accuracy while maintaining reliable measurement stability throughout continuous industrial operation. Furthermore, the optimized input circuitry minimizes electrical interference and improves signal integrity across every connected channel. Engineers also appreciate the compact module because it simplifies cabinet layout and supports efficient system expansion.
Industrial Applications
The TSXAEY1600 supports process automation, power generation, water treatment, chemical production, and manufacturing control systems with dependable analog data collection. In addition, it connects efficiently with pressure transmitters, temperature sensors, flow meters, and level instruments, enabling accurate real-time process monitoring. This capability helps operators improve production consistency while reducing unexpected process deviations.
Why Choose Schneider TSXAEY1600
Schneider Electric designs the TSXAEY1600 to deliver reliable analog acquisition, stable communication, and long-term industrial durability. Therefore, engineers can integrate the module into existing PLC systems confidently while maintaining accurate measurement performance under demanding operating conditions. Its combination of high-resolution conversion, compact dimensions, and dependable industrial reliability makes it an excellent solution for automation applications.
