The TSXAAK1 functions as a resistor adapter module within Schneider’s Modicon TSX automation platform. This compact unit measures roughly 4.7 inches long, 0.8 inches wide, and 2.6 inches high. Moreover, it weighs about 0.3 pounds, so panel space stays efficient. Engineers add the TSXAAK1 when analog inputs need precise resistive signal conditioning.
Technical Specifications and Interface Details
The adapter converts resistive sensor signals into stable voltage values for analog input cards. Specifically, it pairs with RTD and potentiometer inputs across defined measurement ranges. Additionally, screw terminals accept field wiring without special tools. The module mounts directly beside compatible analog modules in the same rack.
| Parameter | Specification |
|---|---|
| Module Type | Resistor Adapter Module |
| Sensor Types | RTD, potentiometer |
| Dimensions | 4.7 x 0.8 x 2.6 in |
| Weight | ~0.3 lbs |
| Interface | Screw terminals |
| Mounting | Rack or panel |
| Compatibility | Modicon TSX analog inputs |
| Operating Range | Industrial temperature range |
Energy Storage and Signal Accuracy
Internal capacitors on the TSXAAK1 provide local energy storage for clean reference voltages. Consequently, the adapter suppresses noise that could distort resistive measurements. This filtering keeps readings stable in electrically noisy cabinets. The design therefore supports consistent accuracy across long service intervals.
Installation and Compatibility Notes
Because the TSXAAK1 mounts beside existing analog modules, technicians complete installation quickly. They should verify wiring polarity before they power the control system. Furthermore, the adapter works with several Modicon TSX input cards. Always store spare units in anti-static packaging to protect sensitive components.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
