The TSX1722028 works as a programmable logic controller module within Schneider’s Modicon TSX platform. This unit measures roughly 10.2 inches long, 1.2 inches wide, and 5.7 inches high. Moreover, it weighs about 1.2 pounds, which suits standard rack mounting. Engineers choose the TSX1722028 when they need dependable process control with straightforward integration.
Technical Specifications and Interface Details
The module executes application programs and therefore manages discrete and analog control tasks. Specifically, it provides onboard memory for program code and process data. Additionally, rear connectors link the unit to the backplane and expansion modules. Front-panel indicators reveal run, fault, and communication status at a glance.
| Parameter | Specification |
|---|---|
| Module Type | PLC Processor Module |
| Function | Logic and process control |
| Dimensions | 10.2 x 1.2 x 5.7 in |
| Weight | ~1.2 lbs |
| Interface | Backplane connectors |
| Indicators | Run, fault, communication LEDs |
| Mounting | Modicon TSX rack |
| Power | 24 VDC nominal |
Energy Storage and Program Retention
A backup battery on the TSX1722028 preserves application code during power interruptions. Consequently, the controller resumes operation without reloading programs from external media. Internal capacitors further stabilize logic voltage across brief supply dips. This buffering therefore protects critical control sequences in continuous production environments.
Installation and Compatibility Notes
Because the TSX1722028 slides directly into Modicon TSX racks, technicians complete installation quickly. They should confirm connector alignment before they apply power to the system. Furthermore, the module integrates smoothly with existing TSX control hardware. Always store spare units in anti-static packaging to protect sensitive circuitry.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
