Key Technical Specifications

This PLC module delivers reliable performance for demanding industrial environments. We designed the TSX07211612 to provide flexible integration and robust data handling.

• Product Type: Programmable Logic Controller Module

• Dimensions: 130 mm x 100 mm x 45 mm (W x H x D)

• Weight: Approximately 0.45 kg

• Power Supply: 24 V DC nominal, with a tolerance of 19.2 V to 30 V

• Current Consumption: 120 mA typical at 24 V DC

• Input/Output Channels: 16 digital inputs and 12 digital outputs

• Output Type: Solid-state, 24 V DC, 0.5 A per channel

• Communication Ports: 1 x RS-232 and 1 x RS-485

• Memory: 64 KB of internal RAM with battery backup

• Battery Backup: Lithium battery retains data for 30 days

• Processing Speed: 0.5 ms per 1K instruction set

• Operating Temperature: 0 °C to 60 °C

• Mounting: Direct DIN-rail or panel mount

• Certifications: CE, UL, and RoHS compliant

Modular Design and Installation

The compact form factor of the TSX07211612 simplifies installation within crowded control cabinets. Its lightweight construction, at just 0.45 kg, reduces mechanical stress on mounting rails. You can secure this module using standard DIN-rail clips or screws for panel mounting. This flexibility allows for quick integration into both new and retrofit projects.

Communication and Connectivity

This module includes two essential communication ports for seamless system integration. The RS-232 port supports direct connections to programming terminals and HMI devices. Meanwhile, the RS-485 port enables robust networking with multiple field devices over longer distances. Consequently, this dual-port design facilitates real-time data exchange with sensors, drives, and supervisory systems.

Performance and Power

The TSX07211612 processes instructions swiftly, with a scan rate of 0.5 ms per 1K instructions. This speed ensures timely control responses for time-critical applications. The built-in 64 KB of battery-backed RAM reliably stores your critical program data and process variables. This memory retains information for up to 30 days, even during power outages, preventing data loss.

Environmental Resilience

This PLC module operates dependably across a wide temperature range. It functions perfectly from 0 °C to 60 °C, making it suitable for various factory floor conditions. The module also complies with CE, UL, and RoHS standards. Therefore, you can confidently deploy it in regulated industries, ensuring both safety and environmental responsibility.
