Core Technical Specifications
The PCE984CBC belongs to the Schneider industrial control range and functions as a clutch and brake controller module. It regulates engagement timing for electromagnetic clutches and brakes in cyclic machinery. Therefore, machine builders rely on this module for accurate stopping and indexing on press feeds and packaging lines.
Full Parameter Table
| Parameter | Specification |
|---|---|
| Model | PCE984CBC |
| Function | Clutch/Brake Controller Module |
| Input Voltage | 24 VDC control input |
| Output Voltage | 90–180 VDC for clutch/brake coils |
| Output Current | 2 A continuous per channel |
| Number of Outputs | 2 independent channels |
| Response Time | 10 ms typical |
| Mounting | Panel or DIN rail mount |
| Terminal Type | Screw terminals |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Weight | Approximately 0.4 kg |
| Dimensions | 130 mm × 90 mm × 50 mm |
Physical Design and Interface Features
The PCE984CBC uses a compact metal housing that mounts on panels or DIN rails. Its screw terminals accept standard field wiring without special tools. Furthermore, the module isolates control inputs from high-voltage outputs, which protects upstream logic devices. Meanwhile, adjustable timing potentiometers let technicians fine-tune engagement delays on site.
System Integration Notes
This controller works together with PLC outputs and electromagnetic clutch/brake assemblies. Consequently, it fits into existing press and feed control panels with minimal rewiring. Engineers set engagement and release timing through front-panel adjustments. However, users should always confirm coil voltage ratings before connecting external hardware.
Details
| Weight | 0.25 kg |
|---|---|
| Dimensions | 130 × 100 × 20 mm |
