The PC0085102 extends I/O capacity within Schneider’s industrial control platform as a dedicated expansion module. This unit measures approximately 5.5 inches long, 1.0 inch wide, and 4.3 inches high. Moreover, it weighs roughly 0.5 pounds, so cabinet space stays efficient. Engineers add the PC0085102 when existing controllers need extra points without full replacement.
Technical Specifications and Interface Details
The module adds discrete input and output channels to the host controller. Specifically, it provides sixteen combined I/O points with defined voltage thresholds. Additionally, a ribbon connector links the unit directly to the main board. LED indicators reveal channel status during operation and service.
| Parameter | Specification |
|---|---|
| Module Type | Expansion I/O Module |
| Points | 16 combined I/O |
| Dimensions | 5.5 x 1.0 x 4.3 in |
| Weight | ~0.5 lbs |
| Interface | Ribbon connector |
| Indicators | Per-channel LEDs |
| Mounting | Panel or rack slot |
| Power | 24 VDC nominal |
Energy Storage and Signal Conditioning
Internal capacitors on the PC0085102 provide local energy storage for clean switching thresholds. Consequently, the module rejects noise from adjacent drives and contactors. This filtering keeps logic readings stable in electrically busy cabinets. The design therefore supports consistent performance across repeated cycles.
Installation and Compatibility Notes
Because the PC0085102 connects through a keyed ribbon cable, technicians complete installation quickly. They should confirm orientation before they apply power to the system. Furthermore, the module integrates smoothly with existing Schneider control hardware. Always store spare units in anti-static packaging to protect sensitive components.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
