Robust Power Delivery for Modicon 984 Controllers
The PC-D984-385 power supply module provides essential DC power for Modicon 984 programmable controller systems. This module accepts a wide input voltage range of 120/220 V AC at 50/60 Hz. It delivers stable power to the CPU, I/O modules, and communication interfaces. This design ensures reliable system operation across various industrial environments.
Current Ratings and Power Specifications
The PC-D984-385 draws 0.5 A at 120 V AC input or 0.2 A at 220 V AC input. The module supports 16K program memory and 2K data memory configurations. It also operates with 512 discrete I/O points, offering sufficient capacity for medium-scale automation tasks. Furthermore, this module demonstrates typical CPU power consumption around 2.115 VA.
Physical Dimensions and Environmental Ratings
This module weighs approximately 1.25 kg and measures 8.4 cm in length. It operates reliably across a temperature range from -5°C to +45°C. The module also features an IP20 protection rating, providing protection against solid objects larger than 12.5 mm. This module also stores safely without damage in proper conditions. It also carries CE, UL, and CSA certifications for international compliance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Line | Modicon 984 |
| Model | PC-D984-385 |
| Module Type | Power Supply Module |
| Input Voltage | 120/220 V AC (selectable) |
| Frequency | 50/60 Hz |
| Current (120V) | 0.5 A |
| Current (220V) | 0.2 A |
| Program Memory Support | 16K |
| Data Memory Support | 2K |
| I/O Capacity | 512 points |
| Power Consumption | 2.115 VA typical |
| Weight | 1.25 kg |
| Dimensions | 8.4 cm (L) |
| Operating Temperature | -5°C to +45°C |
| Protection Rating | IP20 |
| Country of Origin | France |
| Certifications | CE, UL, CSA |
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
