Precision Analog Control
The MWA 16PN provides sixteen analog output channels for Schneider Electric automation systems. This module delivers either 0 to 10 VDC voltage signals or 4 to 20 mA current loops. It converts digital commands from the controller into precise analog values for field devices. The module’s 12-bit resolution ensures fine-grained control over actuators and instruments. Consequently, it serves as a reliable interface between the control system and analog field equipment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model | MWA 16PN |
| Category | Analog Output Module |
| Number of Outputs | 16 (independent) |
| Output Signal Types | 0 to 10 VDC or 4 to 20 mA (selectable) |
| Resolution | 12-bit |
| Interface | Direct I/O connection (rack-mounted) |
| Power Supply | 24 VDC |
| Current Consumption | 50 mA |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Weight | 0.35 kg |
| Environmental Rating | IP20 (dust ingress protection) |
| Status Indicators | LED indicators for operational status |
Hardware Design and Integration
This analog output module features a rack-mounted form factor for straightforward installation . It requires a 24 VDC power supply with a modest current draw of only 50 mA. The IP20 rating protects internal components from dust ingress, enhancing reliability in typical industrial cabinets . LED indicators provide immediate visual feedback on operational status.
Application Suitability
The MWA 16PN excels in applications requiring multiple analog control signals. Typical uses include valve positioning, variable speed drive control, and process setpoint management. The wide operating temperature range supports deployment in diverse factory environments. Its compact design conserves valuable rack space while delivering sixteen outputs .
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
