This compact operator interface terminal provides intuitive human-machine interaction for industrial control systems. The Schneider MMPMC2300 features a 5.7-inch color touchscreen with configurable display pages for process monitoring and parameter adjustment. Its durable construction suits factory floor environments requiring reliable operator input and real-time data visualization.
Key Technical Specifications
| Parameter | Details |
|---|---|
| Model | Schneider MMPMC2300 |
| Product Type | Operator Interface Terminal / HMI |
| Display Size | 5.7 inches (diagonal) |
| Display Type | TFT LCD, 65,536 colors |
| Resolution | 320 x 240 pixels (QVGA) |
| Touch Technology | Resistive analog touchscreen |
| Dimensions (W x H x D) | 166 mm x 126 mm x 48 mm |
| Weight | 0.65 kg |
| Communication Ports | 1 x RS-232, 1 x RS-485, 1 x Ethernet 10/100 Mbps |
| Protocols Supported | Modbus RTU, Modbus TCP/IP, Uni-TE |
| User Memory | 4 MB Flash (application storage) |
| Data Memory | 256 KB RAM (runtime variables) |
| Real-Time Clock | Yes (battery-backed, lithium coin cell) |
| Backlight Type | LED (50,000 hours typical life) |
| Power Supply | 24 V DC ± 20 %, 350 mA typical |
| Operating Temperature | 0 °C to +50 °C |
| Protection Class | IP65 (front panel) |
Display Performance and Visual Quality
The Schneider MMPMC2300 delivers vibrant color graphics through its 5.7-inch TFT LCD with 65,536 color capability. Its 320 x 240 pixel resolution presents clear text, numerical values, and graphical elements for operator comprehension. The LED backlight provides 50,000 hours of continuous illumination, ensuring long-term visibility without replacement concerns. Moreover, the resistive touch technology responds accurately to gloved finger inputs in industrial settings.
Mechanical Construction and Panel Mounting
This operator terminal measures 166 mm wide, 126 mm high, and 48 mm deep, fitting standard panel cutouts with ease. Its 0.65 kg weight allows secure mounting on cabinet doors without additional support brackets. The IP65-rated front panel withstands water jets and dust ingress, making it suitable for washdown areas. Rear-mounted communication ports and power terminals facilitate clean cable routing inside control enclosures.
Connectivity and Protocol Support
The Schneider MMPMC2300 integrates three communication ports: RS-232, RS-485, and Ethernet 10/100 Mbps for flexible network integration. It supports Modbus RTU and Modbus TCP/IP protocols, enabling direct connection to PLCs, drives, and other field devices. The Uni-TE protocol ensures seamless compatibility with Modicon Premium and Quantum controllers. Consequently, this terminal serves as a central monitoring and control point for diverse automation systems.
Memory Configuration and Data Management
This interface terminal provides 4 MB of Flash memory for storing application screens and configuration files permanently. The 256 KB RAM manages runtime variables, alarm logs, and trending data during active operation. A battery-backed real-time clock maintains timestamps for events and production records. Furthermore, operators can download new screen designs through the Ethernet port without halting production.
Power Requirements and Environmental Tolerance
The Schneider MMPMC2300 draws 350 mA at 24 V DC, ensuring efficient power consumption for continuous operation. Its 0 °C to 50 °C operating range accommodates most indoor industrial environments without external cooling. The terminal’s rugged design resists vibration and minor impacts, maintaining reliable performance on moving machinery.
Details
| Weight | 0.65 kg |
|---|---|
| Dimensions | 166 × 126 × 48 mm |
