Core Technical Specifications
The M84A002 belongs to the Schneider Micro-84 controller family and functions as a compact programmable logic controller. It handles discrete and analog control tasks for small to medium automation systems. Therefore, machine builders rely on this controller for cost-effective, reliable process control.
Full Parameter Table
| Parameter | Specification |
|---|---|
| Model | M84A002 |
| Series | Micro-84 |
| Function | Programmable Logic Controller |
| Digital Inputs | 24 points |
| Digital Outputs | 16 points |
| Analog Inputs | 4 channels |
| Analog Outputs | 2 channels |
| Program Memory | 8 KB |
| Communication Ports | RS-232, RS-485 |
| Power Supply | 120/240 VAC |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Weight | Approximately 0.9 kg |
| Dimensions | 200 mm × 120 mm × 75 mm |
Physical Design and Interface Features
The M84A002 uses a compact DIN-rail mountable housing with removable terminal blocks. Its front panel carries status LEDs that indicate power, run, and fault conditions. Furthermore, the controller supports expansion modules, so users can add I/O as their application grows. Meanwhile, the RS-485 port enables multi-drop networking with other controllers and HMIs.
System Integration Notes
This controller works together with Schneider I/O modules and operator panels. Consequently, it fits seamlessly into existing Micro-84 installations. Engineers program the module using standard ladder logic software. However, users must verify firmware compatibility before mixing different production batches.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
