Product Overview
The Schneider EPS 2000 provides regulated DC power for Modicon PLC and I/O systems. This power supply module converts AC mains voltage into stable DC outputs for reliable system operation. Industrial control cabinets depend on this unit for consistent power delivery to all connected modules. The unit’s compact design fits standard rack configurations seamlessly.
Technical Specifications
This power supply features a high-efficiency switching topology for reduced heat generation. The Schneider EPS 2000 includes multiple output rails to support different voltage requirements. Its built-in protection circuits guard against overloads and short circuits. The module’s front panel LEDs indicate power status and fault conditions clearly.
| Parameter | Specification |
|---|---|
| Product Type | Power Supply Module |
| Series Compatibility | Schneider Modicon (Quantum / Premium) |
| Input Voltage | 100-240 V AC (47-63 Hz) |
| Output Voltage (Main) | 5 V DC / 8 A |
| Output Voltage (Aux) | 24 V DC / 2 A |
| Total Output Power | 90 W maximum |
| Efficiency | Typically 87% at nominal load |
| Hold-up Time | Minimum 25 ms at full load |
| Input Protection | Overvoltage, overcurrent, inrush limiting |
| Output Protection | Short-circuit, overvoltage, overtemperature |
| Energy Storage | 6800 µF capacitor bank (primary side) |
| Status Indicators | Power OK (green), Fault (red), Overload (yellow) |
| Dimensions (W x H x D) | 70 mm x 140 mm x 165 mm |
| Weight | Approximately 1.20 kg |
| Connector Type | Screw terminal block (input/output) |
| Mounting | Rack slot insertion or DIN rail |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
Power Output Characteristics
The Schneider EPS 2000 delivers stable 5 V and 24 V DC outputs for system components. Its main 5 V rail powers the CPU, backplane, and I/O modules. The auxiliary 24 V rail supplies field devices and actuators. Both outputs maintain regulation under varying load conditions.
Protection and Reliability
This power supply includes comprehensive protection against electrical faults and surges. The Schneider EPS 2000 automatically shuts down during sustained overload conditions. Its thermal sensors prevent overheating in sealed control cabinets. The module recovers automatically after fault removal.
Installation and Integration
Users insert this module into the designated power supply slot in the rack. The Schneider EPS 2000 connects to the backplane automatically upon insertion. The module requires no configuration or parameter adjustment. Front-accessible terminals allow convenient AC input and DC output connections.
Application Scenarios
System integrators deploy this supply in Modicon control panels across various industries. It powers PLC systems in manufacturing, water treatment, and material handling. The Schneider EPS 2000 provides reliable power for critical automation equipment.
Details
| Weight | 1.20 kg |
|---|---|
| Dimensions | 70 × 140 × 165 mm |
