The DTA 200 compact PLC module delivers flexible control for small to mid-sized automation tasks. This Schneider unit combines processing power with onboard I/O in a single housing. Engineers choose it for space-limited panels and distributed control applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Compact PLC Module |
| Compatibility | AEG Automation Systems |
| Processor | 8-Bit Microcontroller |
| Program Memory | 16 KB EPROM, 8 KB RAM |
| Digital Inputs | 16 Channels, 24 VDC |
| Digital Outputs | 12 Channels, 24 VDC, 0.5 A |
| Interface | RS-232 Serial Port, Backplane Connector |
| Dimensions | 180 mm x 120 mm x 75 mm |
| Weight | Approximately 0.72 kg |
| Component Count | 52 Active Electronic Components |
| Energy Storage | 3.0 V Lithium Backup Battery |
| Power Consumption | 24 VDC at 0.6 A |
| Operating Temperature | 0°C to 55°C |
| Relative Humidity | 5% to 95%, Non-Condensing |
Processing and I/O Capacity
The module runs an 8-bit microcontroller with 16 KB of EPROM program space. Therefore, it handles ladder logic and sequential control routines efficiently. Furthermore, 16 digital inputs and 12 digital outputs cover common machine control needs. Consequently, one unit manages many standalone automation tasks.
Interface and Communication
An RS-232 serial port links the DTA 200 to programming terminals and HMIs. As a result, users download programs and monitor runtime data easily. Additionally, a backplane connector supports expansion with compatible AEG modules.
Power and Backup
The unit draws 24 VDC at 0.6 A from a standard industrial supply. Moreover, a 3.0 V lithium battery protects program memory during outages. Consequently, technicians avoid reloading logic after brief power interruptions.
Installation Notes
Operators mount the module onto a DIN rail or panel inside control cabinets. The compact housing fits tight spaces with minimal clearance requirements. However, users should verify wiring polarity before energizing the inputs.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
