This operator interface delivers precise machine control and real-time process visualization. Its rugged housing ensures reliable operation across demanding factory automation tasks. The panel simplifies navigation through intuitive menu structures and responsive keypad inputs. Operators can monitor production metrics without interrupting ongoing workflows.
Mechanical Dimensions and Mounting Specifications
This unit features a space-saving design suitable for constrained control cabinets. The panel measures 120 mm in width, 75 mm in height, and 45 mm in depth. Its total weight reaches approximately 0.35 kg for minimal mechanical stress on mounting plates. The front bezel carries an IP65 protection rating against dust and low-pressure water jets. Installers need a standard panel cutout of 118 mm x 68 mm for secure fitting.
| Parameter | Specification |
|---|---|
| Model | DBK 111 |
| Display Type | Monochrome LCD with LED backlight |
| Resolution | 128 x 64 pixels |
| Power Supply | 24 V DC (±20%) |
| Current Consumption | 120 mA (typical) |
| Power Dissipation | 2.88 W (maximum) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Communication Ports | RS-232C and RS-485 |
| Mounting Method | Panel clamping system |
Communication Interfaces and Memory Resources
The DBK 111 integrates two serial communication channels for flexible PLC connectivity. A standard DB9 connector handles RS-232 links to legacy controllers. Two dedicated screw terminals support RS-485 networks for multi-drop installations. Internal flash memory stores up to 128 KB of application screens and logic data. The device also includes 512 bytes of EEPROM for retaining critical configuration values. This memory arrangement supports alarm history logs and parameter backups effectively.
Power Efficiency and Environmental Tolerance
This operator panel consumes only 2.88 W under full operational load. Low power draw reduces internal temperature rise and extends component service life. The unit operates within a humidity range of 10% to 90% without condensation risks. It withstands sinusoidal vibration up to 0.5 g across frequencies from 10 to 150 Hz. These specifications guarantee stable performance in conveyor systems and packaging machinery.
Installation Convenience and Protective Features
Mounting the terminal requires minimal tools thanks to its clamp-based fixing system. The rear housing uses high-impact thermoplastic for excellent structural durability. Removable screw terminal blocks simplify wiring and future maintenance tasks. An integrated watchdog timer triggers automatic system resets when needed. This safety mechanism prevents prolonged downtime due to processor anomalies.
Details
| Weight | 0.95 kg |
|---|---|
| Dimensions | 130 × 85 × 120 mm |
