Core Technical Specifications
This Logistat module provides accurate positioning and speed control for material handling systems. We engineered the DAV 103 to deliver reliable performance for demanding logistics automation applications.
| Parameter | Specification |
|---|---|
| Product Type | Logistat Positioning Module |
| Dimensions | 140 mm x 100 mm x 60 mm (W x H x D) |
| Weight | 0.52 kg |
| Supply Voltage | 24 V DC nominal (range: 20.4 V to 28.8 V) |
| Power Consumption | 5 W typical |
| Control Axes | 1 positioning axis |
| Position Resolution | 0.1 mm or 0.1° (configurable) |
| Travel Range | 0 to 99,999 units (configurable) |
| Speed Range | 0 to 100% of rated motor speed |
| Acceleration Profiles | Linear and S-curve ramp generation |
| Input Signals | 2 x 24 V DC (home, limit switch) |
| Output Signals | 2 x 24 V DC (run, direction) |
| Communication Port | 1 x RS-485 (Modbus) |
| Setpoint Memory | 64 user-programmable positions |
| Operating Temp. | 0 °C to 55 °C |
| Mounting | DIN-rail mounted |
| Certifications | CE and UL approved |
Precision Positioning Control
The DAV 103 delivers accurate position control with 0.1 mm or 0.1° resolution across the full travel range. This precision ensures reliable operation for automated storage, conveyor diverters, and picking systems. The module generates both linear and S-curve acceleration profiles for smooth motion control. Consequently, this capability reduces mechanical stress and extends equipment life.
Flexible Travel and Speed Configuration
This positioning module supports a travel range from 0 to 99,999 user-defined units. You can configure the speed from 0 to 100% of rated motor speed for optimal process performance. The output signals control motor run and direction through external drive amplifiers. The module stores up to 64 user-programmable setpoints for rapid position recall.
Comprehensive Input and Output Interface
The DAV 103 includes 24 V DC inputs for home and limit switch connections. These inputs provide reference positions and travel limits for safe operation. The module also offers two 24 V DC outputs for commanding motor run and direction. You can wire these outputs directly to standard motor drives or contactors.
Communication and Setpoint Management
This positioning module communicates through an RS-485 port using the Modbus protocol. This interface allows remote setpoint selection, status monitoring, and real-time position feedback. The 64 on-board setpoint memories store frequently used positions for rapid recall. This feature simplifies operation and reduces training requirements for machine operators.
Robust Design for Industrial Applications
The DAV 103 operates reliably across a 0 °C to 55 °C temperature range for demanding environments. Its DIN-rail mounting simplifies installation and maintenance in control cabinets. The module’s compact dimensions and 0.52 kg weight minimize cabinet space requirements. This robust construction ensures long service life and consistent positioning accuracy.
Details
| Weight | 0.52 kg |
|---|---|
| Dimensions | 140 × 100 × 60 mm |
