Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Processor Module |
| Compatibility | Modicon M580 / M340 PLC Systems |
| Processor Frequency | 150 MHz |
| Program Memory | 8 MB RAM |
| Data Memory | 4 MB RAM |
| User Program Storage | 8 MB Flash Memory |
| Dimensions (H x W x D) | 103 mm x 40 mm x 117 mm |
| Weight | 0.35 kg |
| Power Consumption | 5.0 W typical |
| Current Draw | 200 mA at 5 VDC |
| Battery Backup | 3.0 V lithium battery (user-replaceable) |
| Battery Life | 10 years typical |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 10 % to 95 % (non-condensing) |
| Protection Class | IP20 |
| Certifications | CE, UL, ATEX, IEC 61508 |
Core Processing Capabilities
The ASP892000 processor module delivers robust computational power for complex automation tasks within Modicon M580 and M340 ecosystems. This unit operates at 150 MHz and provides 8 MB of RAM for program execution alongside 4 MB of dedicated data memory. Users can store extensive application code directly in the onboard 8 MB Flash memory, which retains programs even during power interruptions. A replaceable 3.0 V lithium battery maintains real-time clock functions and preserves critical data for up to ten years under normal operating conditions.
Connectivity and Integration
This processor features a built-in USB port for direct connection to programming workstations, enabling fast downloads and online debugging. An integrated Ethernet port supports Modbus TCP/IP communication, allowing seamless integration with supervisory systems and HMIs. The module also includes a serial link for connecting to legacy devices or remote operator panels. Install the ASP892000 directly into any standard rack slot, and it will automatically recognize the backplane configuration upon startup.
Environmental Durability
The ASP892000 operates reliably across industrial environments, withstanding ambient temperatures from 0 °C to 60 °C. Its IP20-rated housing protects internal components from incidental contact and dust ingress. Furthermore, the module meets ATEX and IEC 61508 safety standards, making it suitable for applications requiring functional safety compliance. The compact dimensions and lightweight design simplify installation in space-constrained control cabinets.
Power Management and Efficiency
This processor consumes only 5.0 W of power and draws 200 mA from the 5 VDC backplane supply. Such low energy requirements reduce overall system heat generation and improve long-term reliability. The module’s efficient architecture also minimizes voltage fluctuations, ensuring stable operation for connected I/O modules. For mission-critical applications, consider pairing the ASP892000 with a redundant power supply to maximize uptime.
Details
| Weight | 0.35 kg |
|---|---|
| Dimensions | 103 × 40 × 117 mm |
