Reliable Power Delivery
The ASP830000 operates as a robust power supply module for Schneider Electric automation systems. This unit converts AC mains voltage into stable DC power for control components. It delivers a regulated 24 VDC output with ample current capacity. The module incorporates overvoltage and short-circuit protection features. Consequently, it ensures safe and uninterrupted operation of connected field devices.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model | ASP830000 |
| Category | Power Supply Module |
| Input Voltage | 85-264 VAC (universal) |
| Input Frequency | 47-63 Hz |
| Output Voltage | 24 VDC (nominal) |
| Output Current | 5 A (continuous) |
| Peak Output Current | 6.25 A (for 5 seconds) |
| Efficiency | 88% (typical at 115 VAC) |
| Power Rating | 120 W |
| Ripple & Noise | 50 mV (peak-to-peak, maximum) |
| Hold-up Time | 20 ms at 115 VAC (full load) |
| Inrush Current | 30 A (max at 230 VAC) |
| Protection Features | Overvoltage, short-circuit, overload, overtemperature |
| Operating Temperature | -25°C to +70°C (derating above 50°C) |
| Storage Temperature | -40°C to +85°C |
| Dimensions (W x H x D) | 12.5 cm x 12.0 cm x 7.0 cm |
| Weight | 0.8 kg |
| Mounting | DIN rail (35 mm) or panel mount |
| Terminals | Screw-type, removable (2.5 mm² max) |
| Indicators | Green LED (output OK), Red LED (fault) |
Protection Mechanisms
The ASP830000 incorporates comprehensive protection features for system safety. Overvoltage protection clamps the output at approximately 30 VDC to safeguard sensitive electronics. Short-circuit protection limits current and automatically recovers upon fault removal. Overload protection prevents damage from excessive current draw on the output. Overtemperature protection reduces output current or shuts down temporarily if the unit overheats. These mechanisms collectively enhance the reliability of your entire control system.
Application and Installation
This power supply suits a wide range of factory automation applications. Common uses include powering PLCs, I/O modules, relays, and operator interfaces. The ASP830000 offers a robust, versatile solution for control cabinet power distribution. Its universal AC input range enables global deployment without voltage adjustments. The unit also supports parallel connection with identical modules for load-sharing or redundancy. This flexibility meets diverse system requirements from small machines to large process lines.
Efficiency and Thermal Management
The ASP830000 achieves 88% typical efficiency, minimizing energy waste and heat generation . Its natural convection cooling eliminates the need for fans and reduces maintenance needs.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
