8-Slot Backplane Rack for Modicon 800 Series Systems
The Schneider ASH810208 serves as the backplane rack for the Modicon 800 Series automation platform. This rack provides mechanical support and electrical interconnection for up to eight I/O and communication modules. Its robust construction ensures reliable operation in demanding industrial control environments.
This backplane rack features eight module slots for flexible system configuration. A built-in power supply distribution bus delivers power to all inserted modules. The rack includes mounting provisions for standard DIN rail or panel installation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ASH810208 |
| Type | Backplane Rack |
| Series | Modicon 800 Series |
| Number of Slots | 8 |
| Backplane Bus | X-bus communication bus |
| Power Distribution | 5 VDC and 24 VDC rails |
| Mounting | DIN rail or panel |
| Material | Steel (powder coated) |
| Dimensions | 280 x 120 x 90 mm |
| Weight | 0.85 kg (approx.) |
| Operating Temp | 0 °C to 60 °C |
| Compliance | UL, CSA, CE |
The ASH810208 accommodates up to eight modules including controllers and I/O cards. Its X-bus communication bus ensures deterministic data exchange between modules. The built-in power rails deliver stable 5 VDC and 24 VDC to all slots.
This backplane rack features a durable steel construction for long-term reliability. Its powder-coated finish resists corrosion and wear in industrial environments. The rack supports both DIN rail and panel mounting for installation flexibility.
The ASH810208 integrates with all Modicon 800 Series modules and accessories. Its robust design operates reliably across standard industrial temperature ranges. Therefore, this rack provides a solid foundation for building scalable automation systems.
Details
| Weight | 0.85 kg |
|---|---|
| Dimensions | 280 × 120 × 90 mm |
